> Mercury Marine [Updated: May. 23, 2018] > Outboard > 2 Stroke EFI > 225 (3.0L EFI) > [0T409000 THRU 0T800999] - USA - Cat.# 90-80319902

Cat.# 90-80319902 200/225/250 (EFI L XL XXL SEA PRO 3L MARATHON - TRACKER)

TOP COWL DIAGRAM 1361

880012T1 TOP COWL ASSEMBLY (BLACK)

880012T2 TOP COWL ASSEMBLY (SILVER)

880012T36 TOP COWL ASSEMBLY Silver

880012T1, 880012T2, 880012T36,
880012T1 880012T2 880012T36

MERCURY DECALS

891822A03 DECAL SET (200)

883285A02 DECAL SET (3L SEAPRO)

824105A02 DECAL SET (MERC 225 EFI-LONG)

809693A02 DECAL SET (MERC 225 EFI XL/XXL)(BLUE)(2002)
+ 809693A03 DECAL SET (MERC 225 EFI XL/XXL)(BLUE)(2003)

809167A02 DECAL SET (MERC 250)(2002)
+ 809167A03 DECAL SET (MERC 250)(2003)

MARINER DECALS

883286A02 DECAL SET (3L MARATHON)

827438A02 DECAL SET (MARINER 225 LONG)(2002)
+ 827438A03 DECAL SET (MARINER 225 LONG)(2003)

883284A02 DECAL SET (MARINER 225 XL)(2002)
+ 883284A03 DECAL SET (MARINER 225 XL)(2003)

809168A02 DECAL SET (MARINER 250)(2002)
+ 809168A03 DECAL SET (MARINER 250)(2003)

TRACKER DECALS

809848A02 DECAL SET (TRACKER 225)

OTHER DECALS

804670A02 DECAL EPA Label Information (2002)

804670A03 DECAL EPA Label Information (2003)

22 NSS NOT SOLD SEPARATE Decal-Break-In

23 NSS NOT SOLD SEPARATE Decal-Counter Rotation

Serial Number:
0T789???
2003
250XL EFI SW
Max RPM
HP 250 KW ???
LB 483 KG ???
Mercury Marine
Brunswick Corp.
Fond du Lac, WI 54935
Assembled in the USA
from US and foreign
components
CE [03]

2003 MERCURY 250 HP XL EFI SW:1250423AC, 1250423AY

Serial Number: 0T651254 - Model: 1225433AY - Model Version: XXL SW
2003 MERCURY 3.0L EFI SALTWATER 225EFI XXL SW

Serial Number:
0T651254
2003
225 XXL
Max RPM 5800
HP 225 KW 168
LB 483 KG 219
Mercury Marine
Brunswick Corp.
Fond du Lac, WI 54935
Assembled in the USA
from US and foreign
components
CE [02]

Mercury 809693A03 ORD 37-8M0063720

200HP 0T750164 THRU 0T800999 - USA - Cat. # 90-8 0319902 - 3. 0 L
200HP 0T801000 THRU 1B417701 - USA - Cat. # 90-8 03199004 - 3 . 0L TOP COWL
225HP 0T409000 THRU 0T800999 - USA - Cat. # 90-8 0319902 - 3. 0 L
225HP 0T801000 THRU 1B417701 - USA - Cat. # 90-8 03199004 - 3 . 0L, MARATHON, SEAPRO TOP COWL
250HP 0T409000 THRU 0T800999 - USA - Cat. # 90-8 319902
250HP 0T801000 THRU 1B417701 - USA - Cat. # 90-8 03199004 TOP COWL
3.0 Liter 0T409000 THRU 0T800999 - USA - Cat.# 90-80319902 - MARATHON, SEAPRO

Mariner Outboard 2002 225HP: 7225413LD, 722541ALF, 7225423LY.
Mariner Outboard 2002 250HP: 7250423LY, 7250424LY.

Mariner Outboard 2003 225HP: 7225413MD, 722541AMF, 7225423MY, 722542AMF.
Mariner Outboard 2003 250HP: 7250423MY, 7250424MY.

Mercury Outboard 2002 225HP: 1225413ZD, 1225413ZE, 1225413ZT, 122541AZF, 1225423ZE, 1225423ZY, 1225424ZE, 1225424ZY, 122542AZF, 122542BZF, 1225433ZY, 1225434ZY.
Mercury Outboard 2003 225HP: 1225413AD, 1225413AT, 1225423AY, 1225424AY, 122542BAF, 1225433AY, 1225434AY.

1225413ZD, 1225413ZE, 1225413ZT, 122541AZF, 1225423ZE, 1225423ZY, 1225424ZE, 1225424ZY, 122542AZF, 122542BZF, 1225433ZY, 1225434ZY,
1225413AD, 1225413AT, 1225423AY, 1225424AY, 122542BAF, 1225433AY, 1225434AY,

1225413ZD 1225413ZE 1225413ZT 122541AZF 1225423ZE 1225423ZY 1225424ZE 1225424ZY 122542AZF 122542BZF 1225433ZY 1225434ZY
1225413AD 1225413AT 1225423AY 1225424AY 122542BAF 1225433AY 1225434AY

Mercury Outboard 2002 250HP: 1250423ZE, 1250423ZY, 1250424ZE, 1250424ZY, 1250433ZY, 1250434ZY.
Mercury Outboard 2003 250HP: 1250423AC, 1250423AY, 1250424AC, 1250424AY, 1250433AC, 1250433AY, 1250434AY.

1250423ZE, 1250423ZY, 1250424ZE, 1250424ZY, 1250433ZY, 1250434ZY,
1250423AC, 1250423AY, 1250424AC, 1250424AY, 1250433AC, 1250433AY, 1250434AY,

1250423ZE 1250423ZY 1250424ZE 1250424ZY 1250433ZY 1250434ZY
1250423AC 1250423AY 1250424AC 1250424AY 1250433AC 1250433AY 1250434AY

Serial Number: 0T444337 - Model: 1225413ZD - Model Version: L
2002 MERCURY 3.0L EFI 225EFI L

 > Mercury Marine [Updated: Dec. 13, 2018] > Outboard > 2 Stroke Carb > 30 (2 CYL.) > [0G055314 THRU 0G760299] - USA - Cat.# 90-80874494 > MISCELLANEOUS INFORMATION

TOP COWL DIAGRAM 37304

(1) 821528A5 TOP COWL ASSEMBLY (BLACK) MANUAL
(1) 821528A11 TOP COWL ASSEMBLY (SILVER) MANUAL

(2) 821528A7 TOP COWL ASSEMBLY (BLACK) ELECTRIC
(2) 821528A8 TOP COWL ASSEMBLY (SILVER) ELECTRIC

821528A5, 821528A11, 821528A7, 821528A8
821528A5 821528A11 821528A7 821528A8

MERCURY DECALS

808616A94 DECAL SET (MERC 30) (DESIGN I)
+ 808616A00 DECAL SET

808616A96 DECAL SET (MERC 30) (DESIGN II)
+ 808616A00 DECAL SET

808683A95 DECAL SET (MERC 30 SEAPRO)
+ 808683A01 DECAL SET

824093A94 DECAL SET (MERC 40) (DESIGN I)
+ 824093A00 DECAL SET

824093A96 DECAL SET (MERC 40) (DESIGN II)
+ 824093A00 DECAL SET

808615A95 DECAL SET (MERC 40 SEAPRO)
+ 808615A01 DECAL SET

MARINER DECALS

808682A94 DECAL SET (MARINER 30) [USA 0G437999, BEL 9926999] & Below
+ 808682A03 DECAL SET

824094A94 DECAL SET (MARINER 40) [USA 0G437999, BEL 9926999] & Below
+ 824094A03 DECAL SET

808682A97 DECAL SET (MARINER 30) [USA 0G438000, BEL 9927000] & Up
+ 808682A03 DECAL SET

824094A97 DECAL SET (MARINER 40) [USA 0G438000, BEL 9927000] & Up
+ 824094A03 DECAL SET

808617A95 DECAL SET (MARINER 30 MARATHON)
+ 8582521 DECAL SET

824424A95 DECAL SET (MARINER 40 MARATHON)
+ 8582522 DECAL SET

54321A97 DECAL SET (EXPORT - MARINER 40 “ARRLUK”)
+ 54321A03 DECAL SET

OTHER DECALS

(25) 8555776 DECAL EPA Label Information (INSIDE TOP COWL)(1998)

855577A6 REF OB SB 09-18

Serial No: 0G150913 - Model No: 7031213DD - Model Version: MLH/ALT
1995 MARINER 30 MLH/ALT - (30 H.P.)

Serial Number: Unknown - Model: Unknown - Model Version: ELO possibly

1998 Mercury 40 LO

Mercury Marine [Updated: Apr. 26, 2017]  > Outboard  > 2 Stroke Carb  > 40 (2 CYL.) [0G055314 THRU 0G760299] - USA - Cat.# 90-80874494 30/40 (2 CYL.) 2 Stroke Carb SEA PRO MARATHON ARRLUK
Possible models from 1998:
1041203UB MH-ALT
1041203UD MH-ALT
1041204UB MRC-ALT
1041204UD MRC-ALT
1041207UB MH
1041207UD MH-ALT
1041213UB MLH-ALT
1041213UD MLH-ALT
1041214UB MLRC-ALT
1041214UD MLRC-ALT
1041217UD MLH-ALT
1041227UD MLLH-ALT

1041302UB EO
1041302UD EO

1041312UB ELO
1041312UD ELO

1041412UB ELPTO
1041412UD ELPTO

1043203UD MH-ALT

1043213UD MLH-ALT

1043302UD EO

1043312UB ELO
1043312UD ELO
1043312UN ELO

1043372UD JET 30

1043411UD ELHPTO
1043411UN ELHPTO

1043412UD ELPTO
1043412UN ELPTO

Serial Number:
MISSING??
1998
40 ELO
5500 Max RPM
HP 40 KW 30
LB 197 KG 90
MERCURY MARINE
BRUNSWICK CORP.
FOND DU LAC, WI 54935
MADE IN USA
CE [98]

 > Mercury Marine [Updated: Mar. 21, 2023] > Outboard > 2 Stroke Carb > 25 (2 CYL.) > [1B000001 & Up] - USA - Cat.# 90-803127001
 > Mercury Marine [Updated: Jun. 6, 2018] > Outboard > 2 Stroke Carb > 25 (2 CYL.) > [0T980000 THRU 0T999999] - USA - Cat.# 90-803127001

TOP COWL DIAGRAM 7415

9163T19 TOP COWL ASSEMBLY (Black)
9163T21 TOP COWL ASSEMBLY (Silver)

9163T19, 9163T21
9163T19 9163T21

MERCURY DECALS

824091A00 DECAL SET (Black 20/Jet 20) (2005)
897508A01 DECAL SET (Mercury 20) (2006 and up)
897508A03 DECAL SET (Mercury-Jet 20) (2006 and up)
808499A00 DECAL SET (Black 25) (2005)
897508A02 DECAL SET (Mercury 25) (2006 and up)
+ 8M0098675 DECAL SET
811304A00 DECAL SET (Black SeaPro 25)
+ 8M0098711 DECAL-SERVICE KIT

MARINER DECALS

824092A03 DECAL SET (Gray 20)
824088A03 DECAL SET (Gray 25)

TRACKER DECALS

824731A96 DECAL SET (Tracker) (Tracker 25) (2005)

OTHER DECALS

(15) 134254 DECAL Starting Procedures

(15) 111851 SHIFT DECAL (Jet)

804663A05 DECAL EPA Label Information (2005)
804663A06 DECAL EPA Label Information (2006)
804663A07 DECAL EPA Label Information (2007 and up)

Starter Assembly (Manual) Diagram 5085

(27) 8272822 DECAL Warning High Voltage
(28) NSS NOT SOLD SEPARATE Decal-Servicing Referrral
(29) 37 881865 DECAL Caution-Start in Gear (Start In Gear) (Remote Control)
(30) NSS NOT SOLD SEPARATE Decal-Emergency Start Procedure

Tiller Handle Assembly diagram 5121

(16) 8242002 DECAL (Tiller Handle Shift)
(16) 8242004 DECAL (Side Shift)

Serial Number: 1B207986 - Model: 1025302DD - Model Version: E
2005 MERCURY 25 E
Cat.# 90-803127001 20/25/JET 20 - 20/25 SEAPRO/MARATHON (2-STROKE)

Serial Number: 1B258555 - Model: 1025201FD - Model Version: M
2006 MERCURY 25 M

Serial Number:
1B258555
2006
25 M
Max RPM 6000
HP 25 KW 18.4
LB 114 KG 51.8
Mercury Marine
Brunswick Corp.
Fond du Lac, WI 54935
Assembled in the USA
from US and foreign
components
CE [ 05 ]

> Mercury Marine [Updated: Jan. 1, 2024] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > [6436123 & Up] - USA - Cat.# 90-13290
> Mercury Marine [Updated: Feb. 23, 2023] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > [6436123 & Up] - USA - Cat.# 90-13290
> Mercury Marine [Updated: May. 20, 2022] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > [6436123 & Up] - USA - Cat.# 90-13290
> Mercury Marine [Updated: Apr. 13, 2022] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > [6436123 & Up] - USA - Cat.# 90-13290
> Mercury Marine [Updated: Oct. 3, 2017] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > [7208848 & Up] - Canada Cat.# 90-13290 90/115 H.P. (INLINE)
P
** PROBLEMS DEFINING DECAL SET YEAR WITH THIS CATALOG. MANUAL INSPECTION IS SUGGESTED.

TOP COWL AND SUPPORT BRACKETS DIAGRAM 38408

1- 7934 TOP COWL ASSEMBLY (BLACK)
+ 7934T TOP COWL
1- 6392T6 TOP COWL ASSEMBLY (GRAY)

COWLING AND FRONT COVER (BLACK) DIAGRAM 38409

1 - 7928A3 FRONT COVER ASSEMBLY
9 - 4660A4 WRAP AROUND COWL ASSEMBLY

7934, 7934T, 6392T6, 7928A3, 4660A4

MERCURY DECALS

13137A87 DECAL SET (90)(BLACK)
12832A87 DECAL SET (115)(BLACK)

MARINER DECALS

94937A87 DECAL SET (90)(GRAY)
87132A87 DECAL SET (115)(GRAY)
