1997-2001 HONDA 75/90 HP 65 JET 4S - 90HP BF90AW JHTA JRTA LHTA LRTA XRTA

> Product Lines > Mid - Large Outboard Engines (25 - 250hp) > BF > BF90 > BF90AW LHTA >
MARK

Honda Outboard  BF90AW JHTA JRTA LHTA LRTA XRTA

ENGINE COVER DIAGRAM 14ZW00E1-ZW04F0800B

029. 63100-ZW1-030ZA COVER ASSY., ENGINE *NH282MU* (OYSTER SILVER METALLIC-U)



Diagram 14ZW00E1-ZW04F1200A


1. 87121-ZW0-000 MARK, RR. (BF75)
8. 87301-ZW0-000 MARK, FR. EMBLEM (75)

87121-ZW0-000, 87301-ZW0-000, 87131-ZW1-000, 87132-ZW1-000, 87634-ZW1-H40,
87121-ZW0-000 87301-ZW0-000 87131-ZW1-000 87132-ZW1-000 87634-ZW1-H40

2. 87121-ZW1-000 MARK, RR. (BF90) [1997-2001]
9. 87301-ZW1-000 MARK, FR. EMBLEM (90)

87121-ZW1-000, 87301-ZW1-000, 87131-ZW1-000, 87132-ZW1-000, 87634-ZW1-H40,
87121-ZW1-000 87301-ZW1-000 87131-ZW1-000 87132-ZW1-000 87634-ZW1-H40

15. 87121-ZW1-F40 MARK, RR. (BF65) (JET)

87121-ZW1-F40, 87131-ZW1-000, 87132-ZW1-000, 87634-ZW1-H40,
87121-ZW1-F40 87131-ZW1-000 87132-ZW1-000 87634-ZW1-H40

5. 87131-ZW1-000 MARK, SIDE FOUR STROKE [90-75hp - 1997-2001]
6. 87132-ZW1-000 MARK, SIDE STRIPE HONDA [90-75hp - 1997-2001]

3. 87124-ZV3-620 MARK, EMERGENCY SWITCH INDICATION (ENGLISH)*
4. 87125-ZW1-700 MARK, START (E)*

7. 87152-ZW1-740 LABEL, SPECIFICATION (NMMA)*

10. 87511-ZV1-C20 MARK, CHANGE (JAPANESE/ENGLISH)*
11. 87531-ZW1-740 LABEL, OIL CAUTION (ENGLISH)*

12. 87532-ZV3-620 MARK, THROTTLE (ENGLISH)*
13. 87538-ZW1-740 LABEL, CAUTION OPERATOR (ENGLISH); SEE PART DETAILS - PRI [ 5/8/9.9/15/25/30/40/50/60/75/90/100

14. 87546-ZW1-740 MARK, EMERGENCY START (ENGLISH)*
16. 87634-ZW1-H40 MARK, ENVIRONMENT (EPA 2006)*

Read more: 1997-2001 HONDA 75/90 HP 65 JET 4S - 90HP BF90AW JHTA JRTA LHTA LRTA XRTA

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips

    1. Ensure that the surrounding work area and the surface are properly cleaned to avoid contamination.

    90-8M0143239 eng MARCH 2018       © 2018 Mercury Marine      -     Page 1 / 16
