Evinrude/Johnson JOHNSON 1970 115 115ESL70D 1970 MOTOR COVER GROUP

MOTOR COVER GROUP Diagram 91733 - 1b2c9418-7d89-4042-8f79-9fb4e89ae469

1 0384320 MOTOR COVER ASSEMBLY, Complete

9 0315588 APPLIQUE, Seahorse ,port
14 0315589 APPLIQUE, Motor cover port (sea horse)

11 0314771 APPLIQUE, "johnson"

29 0315694 APPLIQUE, Pennant, stbd.
32 0315697 PLATE, Upper applique stbd. (Flag Top piece)
21 0315594 APPLIQUE, Motor cover stbd (Flag middle piece)
34 0315801 PLATE, Lower applique, stbd (Flag middle piece) 115

30 0315695 PLATE, Flagstaff

28 0315693 APPLIQUE, Pennant, port
31 0315696 PLATE, Upper applique port (Flag Top piece)
15 0315593 APPLIQUE, Motor cover starboard

12 0315146 APPLIQUE, Rear

26 0315703 PLATE, Applique front
27 0315691 APPLIQUE, Motor cover front

0384492 DECAL SET

ENGINE COVER - EVINRUDE Diagram 8b2e182c-9f9d-47da-841a-fe072024db7b

1 0283610 ENGINE COVER ASSY.. 20EE - 20ELE
1 0283609 ENGINE COVER ASSY.. 25EE - 25ELE
1 0283611 ENGINE COVER ASSY.. 30EC - 30ELE
1 0284059 ENGINE COVER ASSY.. TE25ELE

0283610, 0283609, 0283611, 0284059,  0434555, 0433729, 0433728, 0433727

EVINRUDE DECALS

20 0283921 DECAL SET. 20EE - 20ELE 25EE - 25ELE 30EC - 30ELE

6 0211222 PLATE, Frame, front, 20. 20EE - 20ELE
15 0211223 PLATE, Frame, rear, 20. 20EE - 20ELE

6 0211227 PLATE, Frame, front, 25. 25EE - 25ELE
15 0211228 PLATE, Frame, rear, 25. 25EE - 25ELE

6 0211231 PLATE, Frame, front, 30. 30EC - 30ELE
15 0211232 PLATE, Frame, rear, 30. 30EC - 30ELE

20 0284225 DECAL SET. TE25ELE
15 0211692 PLATE, Frame, rear, 25. TE25ELE
6 0211569 PLATE, Frame, front, 25. TE25ELE

ENGINE COVER - JOHNSON Diagram 612b8f14-6bd6-4f84-bb55-2c7f48d4759c

1 0434555 ENGINE COVER ASSY.. TJ25ELE
1 0433729 ENGINE COVER ASSY.. 30EE - 30ELE
1 0433728 ENGINE COVER ASSY.. 25EE - 25ELE
1 0433727 ENGINE COVER ASSY.. 20EE - 20ELE

0434555, 0433729, 0433728, 0433727,  0283610, 0283609, 0283611, 0284059

JOHNSON DECALS

19 0434740 DECAL SET. 20EE - 20ELE
13 0335795 PLATE, Frame, rear, 20. 20EE - 20ELE

19 0435186 DECAL SET. 25EE - 25ELE
13 0335788 PLATE, Frame, rear, 25. 25EE - 25ELE

19 0435192 DECAL SET. 30EE - 30ELE
13 0335796 PLATE, Frame, rear, 30. 30EE - 30ELE

6 0335789 PLATE, Frame, front, 20. 20EE - 20ELE 25EE - 25ELE 30EE - 30ELE

19 0435195 DECAL SET. TJ25ELE
6 0335837 PLATE, Frame, front, 25. TJ25ELE
13 0336673 PLATE, Frame, rear, 25. TJ25ELE

Read more: Evinrude/Johnson 20/25/30 T25

ENGINE COVER - EVINRUDE bb9791bb-3532-40b4-b607-daa74ca00d6c

1 0284718 ENGINE COVER ASSY., 88
1 0284738 ENGINE COVER ASSY., 90 models
1 0284739 ENGINE COVER ASSY., 115
1 0284726 ENGINE COVER ASSY.

0284718, 0284738, 0284739, 0284726,  0434916, 0437258, 0436148, 0436518, 0436149, 0436519, 0436581
0284718 0284738 0284739 0284726  0434916 0437258 0436148 0436518 0436149 0436519 0436581

EVINRUDE DECALS

10 0212478 APPLIQUE, Ev., port & stbd
13 0212495 LENS, Evinrude
20 0284841 DECAL SET

0212478, 0212495, 0284841
0212478 0212495 0284841

16 0212686 LENS, 80
17 0212686 LENS, 80

0212686, 0212686
0212686 0212686

16 0212666 LENS, Front, 90
17 0212522 LENS, Front & rear, 90

0212666, 0212522
0212666 0212522

16 0212667 LENS, Front, 115
17 0212523 LENS, Front & rear, 115

0212667, 0212523
0212667 0212523

20 0284843 DECAL SET, 88

ENGINE COVER - JOHNSON a5c54b01-a224-481a-b284-da0f318254c4

1 0434916 ENGINE COVER ASSY.
1 0437258 ENGINE COVER ASSY., 88
1 0436148 ENGINE COVER ASSY., 90
1 0436518 ENGINE COVER ASSY., 90
1 0436149 ENGINE COVER ASSY., 115
1 0436519 ENGINE COVER ASSY., 115
1 0436581 ENGINE COVER ASSY., 115 Jet, (80)

0434916, 0437258, 0436148, 0436518, 0436149, 0436519, 0436581,  0284718, 0284738, 0284739, 0284726,
0434916 0437258 0436148 0436518 0436149 0436519 0436581  0284718 0284738 0284739 0284726

Johnson Decals

10 0340603 APPLIQUE, Johnson logo
17 0340596 APPLIQUE
17 0340597 APPLIQUE, 90
17 0340598 APPLIQUE, 115
21 0340592 APPLIQUE, Johnson

22 0436303 DECAL SET, 90, 90 models. White Engine Cover
22 0435638 DECAL SET, 115 models White Engine Cover

18 0335263 PLATE, Frame, front, 88 white engine cover
22 0435634 DECAL SET 88 models. White Engine Cover

22 0437764 DECAL SET, 88, 88 models. Smoke Engine Cover

22 0437124 DECAL SET 90/115, 65/80 Jet. Smoke Engine Cover

Read more: Evinrude/Johnson 1995-1996 80/88/90/115/ V4

ENGINE COVER - EVINRUDE Diagram  2c2f0646-2ec9-441f-99ae-a21843e70a5d

1 0282601 ENGINE COVER ASSY., 90 only (Evinrude)
1 0282899 ENGINE COVER ASSY., 110 only (Evinrude)

1 0395835 ENGINE COVER ASSY., 90 only (Johnson)
1 0396899 ENGINE COVER ASSY., 110 only (Johnson)

0282601, 0282899, 0395835, 0396899
0282601 0282899 0395835 0396899

EVINRUDE DECALS

23 0282725 DECAL SET (Evinrude)

21 0210323 PLATE, Applique front (Evinrude)
18 0210640 APPLIQUE, Engine cover, rear 110 only (Evinrude)
19 0210324 APPLIQUE, Engine cover, rear 90 only (Evinrude)

ENGINE COVER - JOHNSON Diagram 02683637-1fd5-448b-bd4f-fb62bc89e47a

JOHNSON DECALS

23 0396337 DECAL SET, 90 only
23 0395959 DECAL SET, 110 only

18 0331164 PLATE, Rear, 90 only
18 0322639 PLATE, Rear, 110 only
21 0331159 PLATE, Applique front

Read more: Evinrude/Johnson - 1986 - 90/110 HP - V4
