> Mercury Marine [Updated: Nov. 14, 2017] > Outboard > 2 Stroke Carb > 115 (6 CYL.) > ARCHIVE CAT 84980

MARINER 115

SERIAL NUMBER
115 (6 CYL.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USA 5738891 THRU 6436122
115 (6 CYL.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CAN 7191308 THRU 7208847

COWLING AND FRONT COVER

Diagram 84980-6

1  6497A7 FRONT COVER ASSEMBLY (W/O DECALS)

11 6498A9 WRAP AROUND COWL ASSEMBLY (W/O DECALS)

MARINER DECALS

87133A79 DECAL SET

Serial Number: 06127600 - Model: 7115620 - Model Version: ELPT
1980 MARINER 115 (6 CYL.) ELPT

> Mercury Marine [Updated: Oct. 3, 2017] > Outboard > 2 Stroke Carb > 225 MARATHON (3.0L CARB) > [0G760300 THRU 0T408999] - USA - Cat.# 90-803196 225 MARATHON (3.0L CARB)

TOP COWL DIAGRAM 24038

814277T18 TOP COWL ASSEMBLY (BLACK)(SEAPRO)
814277A19 TOP COWL ASSEMBLY (SILVER)(MARATHON)
814277T14 TOP COWL ASSEMBLY (BLACK)
814277T15 TOP COWL ASSEMBLY (SILVER)

21 NSS NOT SOLD SEPARATE Decal- Break-In

MERCURY DECALS

822800A96 DECAL SET (BLACK LONG)

824396A99 DECAL SET (BLACK XL/XXL BLUEWATER)

826319A96 DECAL SET (3.0L SEAPRO)(1996- 2000)

826319A01 DECAL SET (3.0L SEAPRO)(2001)

822801A97 DECAL SET (GRAY LONG) (ALSO ORDER STRIPING DECAL BELOW)

809708A97 DECAL SET (GRAY XL/XXL) (ALSO ORDER STRIPING DECAL BELOW)

MARINER DECALS

826320A96 DECAL SET (3.0L MARATHON) (1996-1999)
826320A00 DECAL SET (3.0L MARATHON) (2000 AND ABOVE)

824911A25 DECAL Striping (STRIPING) (ROLL OF 25 FT. - NEED 7.2 FT.)

OTHER DECALS

856985A12 DECAL EPA Label Information (1999)
804670A00 DECAL EPA Label Information (2000)
804670A01 DECAL EPA Label Information (2001)

> Mercury Marine [Updated: May. 18, 2023] > Outboard > 4 Stroke > 9.9 HP Carb (232 cc) > [0H000058 THRU 0H016909] - USA - Cat.# 90-80913195
> Mercury Marine [Updated: Oct. 2, 2017] > Outboard > 4 Stroke > 9.9 (4-STROKE) (232 cc) > [0H000058 THRU 0H016909] - USA - Cat.# 90-80913195 - 9.9 (4-STROKE)(232 cc)

TOP COWL DIAGRAM 37381

854654A3 TOP COWL ASSEMBLY (BLACK) [0H013400] & Up
825553A4 TOP COWL ASSEMBLY (BLACK) [0H013399] & Below
+ 854654T3 COWL-TOP-BLACK

854654A4 TOP COWL ASSEMBLY (SILVER) [0H013400] & Up
825553A5 TOP COWL ASSEMBLY (SILVER) [0H013399] & Below
+ 854654T4 COWL-TOP-SILVER

854654A3, 825553A4, 854654T3, 854654A4, 825553A5, 854654T4,
854654A3 825553A4 854654T3 854654A4 825553A5 854654T4

MERCURY DECALS

826335A96 DECAL SET (BLACK 9.9) [0H013399] & Below
826335A98 DECAL SET (BLACK 9.9) [0H013400] & Below
826335A00 DECAL SET (BLACK 9.9)

809727A96 DECAL SET (BLACK 8 BODENSEE)[0H013399] & Below
809727A98 DECAL SET (BLACK 8 BODENSEE) [0H013400] & Below
809727A00 DECAL SET (BLACK 8 BODENSEE)

MARINER DECALS

826336A95 DECAL SET (GRAY 9.9) [0H009514] & Below (1995-1996)
826336A97 DECAL SET (GRAY 9.9) [0H009515] THRU [0H013399] (1997)
826336A98 DECAL SET (GRAY 9.9) [0H013400] & Up (1998)
826336A03 DECAL SET (GRAY 9.9) (2003)

809710A96 DECAL SET (GRAY 8 BODENSEE) [0H009514] & Below
809710A97 DECAL SET (GRAY 8 BODENSEE) [0H009515] THRU [0H013399]
809710A98 DECAL SET (GRAY 8 BODENSEE) [0H013400] & Up
809710A98 DECAL SET (GRAY 8 BODENSEE)

TRACKER DECALS

853556A97 DECAL SET (9.9 TRACKER)

OTHER DECALS

26) 8302584 DECAL (BLACK/TRACKER) [0H013399] & Below

27
8500534 DECAL (BLACK/TRACKER) [0H013399] & Up
8500534 DECAL (GRAY) [0H013400] & Up
8263367 DECAL (GRAY) [0H013400] & Below

29) 85557723 DECAL EPA Label Information (1998)

SWIVEL HEAD AND STEERING HANDLE DIAGRAM 37399

17) - 8242001 DECAL (SIDE SHIFT)
17) - 8242002 DECAL (HANDLE SHIFT)

Serial Number: 0H001065 - Model: 1F10261RD - Model Version: MH/ALT 4
1995 MERCURY 4 STROKE SIDESHIFT 9.9 MH/ALT 4
Cat.#  90-80913195 - 9.9 /8 (BONDENSEE) 4 STROKE

Serial Number: 0H016381 - Model: 1F10312UD - Model Version: ELRC 4
1998 & Newer MERCURY 4 STROKE 9.9 ELRC 4
Cat.# 90-80913195 9.9 (4-STROKE)(232 cc) 0H00058 THRU OH016909 - USA

Serial Number
0H016381
1998
9.9EL 4ST
5500 max rpm
LB 9.9 KG 7.4
LB 103 KG 47MERCURY MARINE
BRUNSWICK CORP.
FOND DU LAC, WI 54935
MADE IN USA
CE [98]

Serial Number: 0H013810 - Model: 7F10312GD - Model Version: ELRC 4
1998  MARINER 4 STROKE 9.9 ELRC 4

Serial Number
0H013810
1998
9.9EL 4ST
5500Max RPM
9.9 HP  7.4 KW
103 LB  47 KG
BRUNSWICK CORP.
FOND DU LAC, WI 54935
MADE IN USA
CE [98]

 > Mercury Marine [Updated: Sep. 29, 2017] > Outboard > 2 Stroke Carb > 50, 500 (4 CYL.) > ARCHIVE CAT 48425 MERC 500-7/8 SERIAL NUMBER 2305101 THRU 2858813

50, 500 (4 CYL.) - Cat# 90-48425 MERC 500-7/8 (1968, 1969, 1970)

TOP COWL ASSEMBLY 500-7/8 P2

3348 TOP COWL - 1970 MODEL 1500100 TOP COWL ASSEMBLY

2954 TOP COWL - 1970 MODEL 1500100 TOP COWL ASSEMBLY

COWLING AND FRONT COVER 500-7/8 P6

1
2654A14 COWL FRONT COVER ASSEMBLY
2654A17 COWL FRONT COVER ASSEMBLY

10
3247A3 WRAP AROUND COWL ASSEMBLY

MERCURY DECALS

47867A1 DECAL SET( MERC 500-7)
52812A1 DECAL SET (MERC 500-8)
