Outboard decal Replicas - Find them here!

115 PRO XS (4-STROKE) - Cat.# 90-8M0114280

> Mercury Marine [Updated: May. 5, 2025] > Outboard > 4 Stroke EFI > 115 HP EFI Pro XS > [2B225488 & Up] - USA - Cat.# 90-8M011428090-8M0114280


Top Cowl Diagram 55117

8M0114282 TOP COWL ASSEMBLY Mercury Pro XS Decaled
8M0091789 TOP COWL ASSEMBLY Black, Non-Decaled

Will also fit on:
8M0087994 TOP COWL ASSEMBLY Mercury Decaled Horse Power, Command Thrust and Jet Decals not included
8M0159539 TOP COWL ASSEMBLY Mercury Decaled New models [2B679490] & Up
8M0090833 TOP COWL ASSEMBLY Mariner Decaled Horse Power, Command Thrust and Jet Decals not included
8M0091789 TOP COWL ASSEMBLY Black, Non-Decaled
8M0087995 TOP COWL ASSEMBLY Gray, Non-Decaled
8M0096296 TOP COWL ASSEMBLY Mercury, Decaled SeaPro

8M0114282, 8M0091789, 8M0087994, 8M0159539, 8M0090833, 8M0091789, 8M0087995, 8M0096296
8M0114282 8M0091789 8M0087994 8M0159539 8M0090833 8M0091789 8M0087995 8M0096296



MERCURY DECALS

> Mercury Marine [Updated: May. 5, 2025] > Outboard > 4 Stroke EFI > 115 HP EFI Pro XS > [2B225488 & Up] - USA - Cat.# 90-8M0114280

Decals-Top and Lower Cowl

1) 8M0114440 DECAL SET Top Cowl 115 HP ProXS
2) 8M0159890 DECAL Lenz Mercury
3) 8M0178226 DECAL M-ICON, Red
4) 8M0159386 DECAL CT - Command Thrust
5) 8M0080155 DECAL - M ICON 29 MM Red
6) 8M0085373 DECAL M-Icon, 60mm Red
7) 8M0114441 DECAL SET Lower Cowl 115 HP ProXS



> Mercury Marine [Updated: Jan. 27, 2023] > Outboard > 4 Stroke > 115 HP EFI Pro XS > [2B225488 & Up] - USA - Cat.# 90-8M0114280
> Mercury Marine [Updated: Mar. 29, 2022] > Outboard > 4 Stroke > 115 HP EFI Pro XS > [2B225488 & Up] - USA - Cat.# 90-8M0114280
> Mercury Marine [Updated: Jul. 28, 2018] > Outboard > 4 Stroke > 115 PRO XS (4-STROKE) > [2B225488 & Up] - USA - Cat.# 90-8M0114280
> Mercury Marine [Updated: Oct. 16, 2019] > Outboard > 4 Stroke > 115 PRO XS (4-STROKE) > [2B225488 & Up] - USA - Cat.# 90-8M0114280

Decals-Top and Lower Cowl Diagram 60348

1) 8M0114440 DECAL SET Top Cowl 115 HP ProXS

N2) 8M0159386 DECAL CT - Command Thrust

N3) 8M0178226 DECAL M-ICON, Red - Top M Logo
3) 8M0080155 DECAL - M ICON 29 MM Red - Rear M Logo
4) 8M0085373 DECAL M-Icon, 60mm Red - Front M Logo

2-N6) 8M0114441 DECAL SET Lower Cowl 115 HP ProXS - Lower cowl stripes



(14x29 2.07:1) Ratio decal for the lower unit

Gear Housing, Driveshaft 2.07:1 Standard Rotation
Gear Housing, Propeller Shaft 2.07:1 Standard Rotation

8M0088072 GEARCASE Complete Long

8M0144823 GEARCASE Complete, Long Silver
+ 8M0227980 GC ASSY-L SLVR ST

8M0088074 GEARCASE Complete X-Long

8M0144824 GEARCASE Complete, X-Long Silver
+ 8M0227981 GC ASY-XL SLVR ST

8M0091538 GEARCASE Basic

8M0145316 GEAR HOUSING Basic Silver
+ 8M0227985 GEARCASE-BASIC ST



(13x31 2.38:1) Ratio decal for the lower unit

Gear Housing, Driveshaft 2.38:1 Standard Rotation

8M0057747 GEAR HOUSING Basi
8M0145314 GEAR HOUSING Basic (CT) Silver


Gear Housing, Propeller Shaft 2.38:1 Standard Rotation

8M0088073 GEARCASE Complete CT Long

8M0144825 GEARCASE Complete CT Long
+ 8M0227982 GC ASY-L SLVR CT

8M0088075 MERCURY OEM GC X-LONG CT
8M0144826 GEARCASE Complete CT X-Long
+ 8M0227983 GC ASY-XL SLVR CT

Read more: 115 PRO XS (4-STROKE) - Cat.# 90-8M0114280

25 (4-STROKE) - Cat.# 90-80301502

> Mercury Marine [Updated: Apr. 30, 2018] > Outboard > 4 Stroke > 25 (4-STROKE) > [0P153500 THRU 0P388282] - Belgium - Cat.# 90-80301502

Top Cowl Diagram 1240

1
830562T5 TOP COWL ASSEMBLY Manual-Black
830562T6 TOP COWL ASSEMBLY Manual Silver

2
830562T7 TOP COWL ASSEMBLY Electric-Black
830562T8 TOP COWL ASSEMBLY Electric-Silver

830562T5, 830562T6, 830562T7, 830562T8
830562T5 830562T6 830562T7 830562T8

MERCURY DECALS

854693A00 DECAL SET (MERCURY)(TRACKER)(2002-2004)
+ 854693A05 DECAL SET
+ + 8M0098694 DECAL SET
854693A05 DECAL SET (MERCURY/TRACKER)(2005)
+ + 8M0098694 DECAL SET



MARINER DECALS

854692A01 DECAL SET (MARINER)(2001)(2002)
854692A03 DECAL SET (MARINER)(2003 AND ABOVE)
854692A98 DECAL SET Mariner 1998 thru 2000
8M0098292 DECAL SET MA 25 4S [1C262470] & Up



Other Decals

804653A02 DECAL EPA Label Information (2002)
804653A03 DECAL EPA Label Information (2003)
804653A04 DECAL EPA Label Information (2004)
804653A05 DECAL EPA Label Information (2005)
804653A06 DECAL EPA Label Information (2006)
88343312 DECAL California Ultra Low Emissions

This Mercury Marine 854693A05 DECAL SET (MERCURY/TRACKER)(2005) is used on these models:
2002 1B25203ZB, 1B25213ZB, 1B25301ZB, 1B25302ZB, 1B25311ZB, 1B25312ZB, 1B25412ZB, 1F25203ZB, 1F25203ZD, 1F25213ZB, 1F25213ZD, 1F25301ZB, 1F25301ZD, 1F25302ZB, 1F25302ZD, 1F25311ZB, 1F25311ZD, 1F25312ZB, 1F25312ZD, 1F25312ZN, 1F25412ZB, 1F25412ZD, 1F25412ZN, 7F25203LB, 7F25203LD, 7F25213LB, 7F25213LD, 7F25301LB, 7F25301LD, 7F25302LB, 7F25302LD, 7F25311LB, 7F25311LD, 7F25312LB, 7F25312LD, 7F25412LB, 7F25412LD Service-Support Material
2003 1B252033B, 1B25203AB, 1B252133B, 1B25213AB, 1B25301AB, 1B25302AB, 1B25311AB, 1B25312AB, 1B254123B, 1B25412AB, 1F252033B, 1F25203AB, 1F25203AD, 1F25213AB, 1F25213AD, 1F25301AB, 1F25301AD, 1F253023B, 1F25302AB, 1F25302AD, 1F25311AB, 1F25311AD, 1F25311AE, 1F253123B, 1F25312AB, 1F25312AD, 1F25312AN, 1F25321AN, 1F254123B, 1F25412AB, 1F25412AC, 1F25412AD, 1F25412AE, 1F25412AN, 7F252033B, 7F25203MB, 7F25203MD, 7F252133B, 7F25213MB, 7F25213MD, 7F25301MB, 7F253023B, 7F25302MB, 7F25302MD, 7F25311MB, 7F25311MD, 7F253123B, 7F25312MB, 7F254123B, 7F25412MB, 7F25412MD Service-Support Material
2004 1B25203CB, 1B25213CB, 1B25412CB, 1F25203CB, 1F25203CD, 1F25213CB, 1F25213CD, 1F25302CB, 1F25302CD, 1F25311CD, 1F25311CN, 1F25312CB, 1F25312CD, 1F25312CN, 1F25412CB, 1F25412CC, 1F25412CD, 1F25412CN, 7F25203RB, 7F25213RB, 7F25213RD, 7F25302RB, 7F25312RB, 7F25312RD, 7F25412RB, 7F25412RD Service-Support Material
2005 1B25203DB, 1B25213DB, 1B25412DB, 1F25203DB, 1F25203DD, 1F25213DB, 1F25213DD, 1F25302DB, 1F25302DD, 1F25311DD, 1F25312DB, 1F25312DD, 1F25312DN, 1F25412DB, 1F25412DC, 1F25412DD, 1F25412DN, 7F25203TB, 7F25213TB, 7F25213TD, 7F25302TB, 7F25312TB, 7F25312TD, 7F25412TB, 7F25412TD Service-Support Material
2006 1F25203FD, 1F25213FD, 1F25302FD, 1F25311FD, 1F25312FD, 1F25412FD.
Serial Number: 1B269372 - Model: 1F25412FD - Model Version: ELPT 4
2006 MERCURY 4 STROKE 25 ELPT 4 - Cat.# 90-80301502 25 (4-STROKE)
Serial Number: 0P295827 - Model: 7F25412RB - Model Version: ELPT/BF 4
S.N. OP295827
25PT4S
2004
5750 MAX RPM
HP 25,0 KW 18,6
LB 172 KG 78
MARINE POWER EUROPE, Inc.
4800 VERVIERS
MADE IN BELGIUM
CS [04]
Serial Number: 0T561633 - Model: 1B25412YB - Model Version : ELH/BF 4
2002 MERCURY 4 STROKE BIGFOOT 25 ELH/BF 4



2 Stroke Carb - 45/50, 450/500 (4 CYL.) - [8063985 & Up] - Cat.# 90-13287 - (1984-1986)

> Mercury Marine [Updated: Mar. 13, 2024] > Outboard > 2 Stroke Carb > 45, 450 (4 CYL.) > [8063985 & Up] - Cat.# 90-13287
> Mercury Marine [Updated: Mar. 19, 2020] > Outboard > 2 Stroke Carb > 50, 500 (4 CYL.) > [5531630 & Up] - USA - Cat.# 90-13287


COWLING DIAGRAM 38555

1)
7938 TOP COWL ASSEMBLY (MANUAL) (MERCURY)
7937A8 TOP COWL ASSEMBLY (ELECTRIC) (MERCURY)
7938F2 TOP COWL ASSEMBLY (MANUAL) (DARK GRAY)(MARINER)
7938F4 TOP COWL ASSEMBLY (MANUAL) (LIGHT GRAY)(MARINER)
7937F2 TOP COWL ASSEMBLY (ELECTRIC) (DARK GRAY) (MARINER)
7937F4 TOP COWL ASSEMBLY (ELECTRIC) (LIGHT GRAY) (MARINER)

15)
 5642A13 COVER ASSEMBLY Cowl - Front [USA-5796395/Aus-8069214/Bel-9291995/Can-7165752] & Below
7927A5 FRONT COVER MERCURY [USA-5796396/Aus-8069215/Bel-9291996/Can-7165753] & Up
7927A12 FRONT COVER MARINER DARK GRAY [USA-5796396/Aus-8069215/Bel-9291996/Can-7165753] & Up
7927A19 FRONT COVER MARINER LIGHT GRAY  [USA-5796396/Aus-8069215/Bel-9291996/Can-7165753] & Up

25)
3247A3 TOP COWL ASSEMBLY Wrap Around - Mercury
8181A2 WRAP AROUND COWL MARINER DARK GRAY
8181A4 TOP COWL ASSEMBLY Wrap Around - Mariner LIGHT GRAY



MERCURY DECALS

93151A81 DECAL SET (BLUE)(MERC 50) (1981)
43198A84 DECAL SET (BROWN)(MERC 50) (1984)
13482A86 DECAL SET (MERC 45) (1986)

MARINER DECALS

94260A81 DECAL SET (DARK GRAY COWLS)(MARINER 50) (1981)
11621A85 DECAL SET (LIGHT GRAY COWLS)(MARINER 50) (1985)
11621A86 DECAL SET (MARINER 45) (1986)



This Mercury Marine 43198A84 DECAL SET (BROWN)(MERC 50) 1984 is used on these models and components:

1980 1050200, 1050220, 1050500, 1050520, 1050530, 1050550, 1050620, 7050200, 7050220, 7050500, 7050520, 7050550.
1982 1050202, 1050222, 1050502, 1050522, 1050532, 1050552, 1050622, 7050622.
1983 1050203, 1050223, 1050243, 1050503, 1050523, 1050533, 1050553, 1050623, 7050503, 7050523, 7050553, 7050623.
1984 1050204, 1050224, 1050504, 1050524, 1050534, 1050554, 1050624.
1985 1050205, 1050225, 1050525, 1050555, 1050625, 7050225, 7050525, 7050555, 7050625.
1986 7050716, 7050726.

This Mercury Marine 13482A86 DECAL SET (MERC 45) 1986 is used on these models and components:
1986 1045216, 1045236, 1045716, 1045726, 1045776, 7045226, 7045716, 7045726, 7045776.

Serial Number: 6488535 - Model: 1050624  - Model Version: ELPT
1984 MERCURY 50 ELPT
Serial Number: 0A915842 - Model: 1045726 - Model Version: ELPTO
1986 MERCURY 45 ELPTO

250 PRO XS (3.0L) - Cat.# 90-898101403

> Mercury Marine [Updated: Oct. 21, 2021] > Outboard > 2 Stroke DFI (OptiMax) > 250 PRO XS (3.0L DFI) > [1B426561 THRU 1B752546] - USA - Cat.# 90-898101403
> Mercury Marine [Updated: Sep. 15, 2021] > Outboard > 2 Stroke DFI (OptiMax) > 250 PRO XS (3.0L DFI) > [1B426561 THRU 1B752546] - USA - Cat.# 90-898101403
> Mercury Marine [Updated: Apr. 8, 2021] > Outboard > 2 Stroke DFI (OptiMax) > 250 PRO XS (3.0L DFI) > [1B426561 THRU 1B752546] - USA - Cat.# 90-898101403
> Mercury Marine [Updated: Feb. 19, 2019] > Outboard > 2 Stroke DFI (OptiMax) > 250 PRO XS (3.0L DFI) > [1B426561 THRU 1B752546] - USA - Cat.# 90-898101403

250 PRO XS (3.0L)


Top cowl diagram 1646

1
881288T58 TOP COWL ASSEMBLY (Includes all Decals except HorsePower) SN# 1B446999 & Below
881288T66 TOP COWL ASSEMBLY (Includes all Decals except HorsePower) SN# 1B447000 & Up
+ 8M0063392 ORD 100-8M0075372
++ 8M0075372 TOP COWL ASSEMBLY Mercury, Without decals

8M0075372 TOP COWL ASSEMBLY (Includes all Decals except HorsePower) SN# 1B446999 & Below
8M0075372 TOP COWL ASSEMBLY, (Black) (Includes all Decals except HorsePower) SN# 1B447000 & Up

881288T58, 881288T66, 8M0063392, 8M0075372,
881288T58 881288T66 8M0063392 8M0075372


MERCURY DECALS

+897136A07 DECAL SET, 250 ProXS ***DECAL SET ProXS, HP decal not included



Lower cowl diagram 27131




1-  850302A07 BOTTOM COWL, Port
3-  850301A07 BOTTOM COWL, Starboard
Serial Number: 1B555079 - Model: 1250P73HD - Model Version: L PROXS
2006 MERCURY OPTIMAX PROXS 250DFI L PROXS
Serial Number: 1B532973 - Model: 1250P73HD - Model Version: L PROXS
2006 MERCURY OPTIMAX PROXS 250DFI L PROXS
Serial Number: 1B722289 - Model: 1250P73HD - Model Version: L PROXS
2006 MERCURY OPTIMAX PROXS 250DFI L PROXS

Serial Number
1B722289
SEP 2008
250XS L
Max RPM 6000
HP 250 KW 186
LB 516 KG 235
Mercury Marine
Brunswick Corp.
Fond du Lac, WI 54935
Assembled in the USA
from US and foreign
components
           [08]
Serial Number: 1B458921 - Model: 1250P73HD - Model Version: L PROXS
MERCURY OPTIMAX PROXS 250DFI L PROXS
Serial Number: 1B458921 - Model: 1250P73HD - Model Version: L PROXS
MERCURY OPTIMAX PROXS 250DFI L PROXS

More Articles …

  1. 9.9/13.5/15 (323CC) 8/9.9/15 BODENSEE 4-STROKE - Cat.# 90-803183
  2. MERCURY GEN 2 135/150/175/200 4-STROKE VERADO - Cat.# 90-898164008
  3. 40/50 (3 CYLINDER) 2-STROKE - Cat.# 90-803026001
  4. MERCURY 2.5L DFI OPTIMAX 135DFI CXL - (135DFI H.P. (2000 ))

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips

    1. Ensure that the surrounding work area and the surface are properly cleaned to avoid contamination.

    90-8M0143239 eng MARCH 2018       © 2018 Mercury Marine      -     Page 1 / 16
