E88MSLCUS
1987 ENGINE COVER - EVINRUDE Diagram 398856-03

1988 ENGINE COVER - EVINRUDE Diagram 432233-04

0283262 ENGINE COVER ASSY., Evinrude

0283677 ENGINE COVER ASSY., 100STL
0283098 ENGINE COVER ASSY., 90 models
0283099 ENGINE COVER ASSY., 110 models

ENGINE COVER - JOHNSON

0398809 ENGINE COVER ASSY., Johnson
0397820 ENGINE COVER ASSY., 90 models
0397821 ENGINE COVER ASSY., 110 models
0432747 ENGINE COVER ASSY., 100STL

0283262, 0283677, 0283098, 0283099, 0398809, 0397820, 0397821, 0432747
0283262 0283677 0283098 0283099 0398809 0397820 0397821 0432747

EVINRUDE DECALS

17) 0210917 PLATE, Front & Rear
22) 0283348 DECAL SET, Evinrude

PAINT CHART

Read more: 1987-1988 88hp Evinrude SPL

ENGINE COVER -- JOHNSON - Diagram 439298-03A PCA0847C 3-95

0438324 ENGINE COVER ASSY.. 20SR Only
0438326 ENGINE COVER ASSY.. 25BA, 25BAL, 25RD, 25R, 25RL
0438328 ENGINE COVER ASSY.. 30BA, 30BAL
0438330 ENGINE COVER ASSY.. 25JR Only

0438324, 0438326, 0438328, 0438330
0438324 0438326 0438328 0438330

Johnson Decals

19 0438437 DECAL SET

6   0343188 PLATE, Frame, front. 20SR Only
18 0343189 PLATE, Frame, rear. 20SR Only

6   0343185 PLATE, Frame, front. 25JR Only
18 0343186 PLATE, Frame, rear. 25JR Only

6   0343190 PLATE, Frame, front. 25BA, 25BAL, 25RD, 25R, 25RL
18 0343191 PLATE, Frame, rear. 25BA, 25BAL, 25RD, 25R, 25RL

6   0343192 PLATE, Frame, front. 30BA, 30BAL
18 0343193 PLATE, Frame, rear. 30BA, 30BAL

Paint Diagram 439298-00B

ENGINE COVER - JOHNSON Diagram 435887-06

1 0435970 ENGINE COVER ASSY.. 150EL, 150EXA, 150NXA
1 0435169 ENGINE COVER ASSY.. 150GL
1 0435964 ENGINE COVER ASSY.. 150NXE, 150EXE
1 0434670 ENGINE COVER ASSY.. TJ150GL
1 0435165 ENGINE COVER ASSY.. 150JL
1 0435167 ENGINE COVER ASSY.. 150ELA
1 0435965 ENGINE COVER ASSY.. 175EXE, 175NXE
1 0435171 ENGINE COVER ASSY.. 175GL
1 0435971 ENGINE COVER ASSY.. 175NXA, 175EXA

0435970, 0435169, 0435964, 0434670, 0435165, 0435167, 0435965, 0435171, 0435971
0435970 0435169 0435964 0434670 0435165 0435167 0435965 0435171 0435971

ENGINE COVER - EVINRUDE Diagram 435887-05
1 0284446 ENGINE COVER ASSY.. 150EL,150EXA,150NXA
1 0284440 ENGINE COVER ASSY.. 150EXE,150NXE
1 0284208 ENGINE COVER ASSY.. 150JL
1 0284197 ENGINE COVER ASSY.. 150GL
1 0284199 ENGINE COVER ASSY.. 175GL
1 0284070 ENGINE COVER ASSY.. TE150GL
1 0284441 ENGINE COVER ASSY.. 175EXE,175NXE
1 0284447 ENGINE COVER ASSY.. 175NXA,175EXA

0284446, 0284440, 0284208, 0284197, 0284199, 0284070, 0284441, 0284447
0284446 0284440 0284208 0284197 0284199 0284070 0284441 0284447

ENGINE COVER - QUIET RIDER Diagram 435887-38
0435944 ENGINE COVER ASSY.

0435944

JOHNSON DECALS

9 0337719 APPLIQUE, Counter rotating. 150EL, 150EXA, 150NXA 175NXA, 175EXA

9 0336817 APPLIQUE. TJ150GL
14 0435247 DECAL SET. TJ150GL

11 0337724 APPLIQUE, V6, front. 150GL 175EXE, 175NXE
14 0435648 DECAL SET. 150GL
14 0436321 DECAL SET. 175EXE, 175NXE

13 0337719 APPLIQUE, Rear. 175NXA, 175EXA
14 0435650 DECAL SET. 175NXA, 175EXA

14 0435645 DECAL SET. 150EL, 150EXA, 150NXA
14 0436320 DECAL SET. 150NXE, 150EXE
14 0435647 DECAL SET. 150JL
14 0435646 DECAL SET. 150ELA

14 0435651 DECAL SET. 175GL

Read more: 1993 Johnson 150  HP J150EXETR

Johnson 1996 88/90/115 80JET
BJ115TLEDA
HJ115TXADA
J115TLEDA
J115TXADA

ENGINE COVER - JOHNSON Diagram 438214-03A

1 0434916 ENGINE COVER ASSY., 88. White Engine Cover
1 0437258 ENGINE COVER ASSY., 88. Smoke Engine Cover
1 0436148 ENGINE COVER ASSY., 90. White Engine Cover
1 0436518 ENGINE COVER ASSY., 90. Smoke Engine Cover
1 0436149 ENGINE COVER ASSY., 115. White Engine Cover
1 0436519 ENGINE COVER ASSY., 115. Smoke Engine Cover
1 0436581 ENGINE COVER ASSY., 115 Jet, (80)

ENGINE COVER - EVINRUDE
1 0284718 ENGINE COVER ASSY., 88 models
1 0284738 ENGINE COVER ASSY., 90 models
1 0284739 ENGINE COVER ASSY., 115
1 0284726 ENGINE COVER ASSY., 115 Jet, (80)

0434916, 0437258, 0436148, 0436518, 0436149, 0436519, 0436581,
0284718, 0284738, 0284739, 0284726,
0434916 0437258 0436148 0436518 0436149 0436519 0436581
0284718 0284738 0284739 0284726

JOHNSON DECALS

21 0340592 APPLIQUE, Johnson (2 decals)
10 0340603 APPLIQUE, Johnson logo (2 decals)

22 0437124 DECAL SET, 90/115, 80 Jet. Smoke Engine Cover
17 0340597 APPLIQUE, 90 (2 decals)
17 0340598 APPLIQUE, 115 (2 decals)
17 0340596 APPLIQUE, 80 (2 decals)

22 0437764 DECAL SET, 88 models. Smoke Engine Cover

13 0331856 FRAME, Front, 88 models
18 0335263 PLATE, Front & rear, 88 models. White Engine Cover (2 decals)
19 0331420 FRAME, Engine cover, 88 models. White Engine Cover

22 0435634 DECAL SET, 88 models. White Engine Cover
22 0436303 DECAL SET, 90 models. White Engine Cover
22 0435638 DECAL SET, 115 models. White Engine Cover
