Outboard decal Replicas - Find them here!

Outboard Decals

Yamaha 6B / 8B 677 Outboard

Yamaha 8b. 677 aussenborder
1973 1977 1978 1979 1980
oil 1:100
MARINER 8B HOOD TOP COVER COWLING

FITS: 6B & 8B MARINER (YAMAHA)
Yamaha Mariner 8 hp top cowling outboard 1978-1997

Here we have a top cowling assembly for a 1978-1997 8 HP Mariner outboard with the serial range: 677-383147 & Up - (1980's) it may fit other models.

Mariner 8 hp outboard with the model/serial number: 8M 677-5056140

This product fits the following:
Mercury Mercury & Mariner Outboard Parts by HP & Liter 8HP 677-300101 AND UP - Cat. #90-83774
Related Fitment
This Mercury 9378M TOP COWL fits the following models and components:

Mercury Mercury & Mariner Outboard Parts by HP & Liter
8HP 677-300101 AND UP - Cat. #90-83774 COWLING
8HP 677-383147 & Up - Cat.# 90-11360 COWLING
8HP 677-057507 & Up - Cat.# 90-11360 COWLING
8HP 677-000101 AND UP - Cat. #90-83774 COWLING
8HP 680K-300302 & Up - USA - Cat.# 90-804373 COWLING
8HP 680-348706 & Up - USA - Cat.# 90-804373 COWLING
8HP 680-304926 THRU 680-348705 ML - Cat. #90-94809 - 8K COWLING
8HP 680-001986 & Up - Belgium - Cat.# 90-804373 COWLING
8HP 680-000551 THRU 680-001985 M - Cat. #90-94809 - 8K COWLING
8HP 677-702821 & Up - Cat.# 90-11360 COWLING

Mercury Outboard Parts by Year (Mercury, Mariner, Mark, Force, Chrysler, Sears, SportJet) Mariner Outboard
1978 7008208 COWLING
1978 7008248 COWLING
1978 7008238 COWLING
1978 7008228 COWLING
1985 7008305 COWLING
1985 7008325 COWLING
1985 7008425 COWLING
1986 7008306 COWLING
1989 8HP 7008218PW COWLING
1990 8HP 7008218SW COWLING
1991 7008218YW COWLING
1992 7008218AW COWLING
1993 7008218BW COWLING
1994 8HP 7008218CW COWLING
1995 8HP 7008218DW COWLING
1996 8HP 7008218EW COWLING
1997 8HP 7008218FW COWLING
1998 8HP 7008218GW COWLING





225/250 EFI (3.0L) XL EFI - Cat.# 90-80917095

 > Mercury Marine [Updated: Oct. 28, 2020] > Outboard > 2 Stroke EFI > 225 (3.0L EFI) > [0G129222 THRU 0G760299] - USA - Cat.# 90-80917095


TOP COWL DIAGRAM  37783

814277A14 TOP COWL ASSEMBLY (BLACK)
+814277T14 TOP COWL ASSEMBLY
814277A15 TOP COWL ASSEMBLY (SILVER)
+814277T15 TOP COWL ASSEMBLY
814277A25 TOP COWL ASSEMBLY (WHITE)
+814277T25 TOP COWL ASSEMBLY

MERCURY DECALS

824105A96 DECAL SET (225 BLACK LONG)
+824105A00 DECAL SET

809693A96 DECAL SET (225 BLACK XL/XXL)
+809693A00 DECAL SET

809167A96 DECAL SET (250 BLACK)
+809167A00 DECAL SET

MARINER DECALS

809709A96 DECAL SET (225 GRAY LONG) [0G437999] & Below
+809709A97 DECAL SET

827438A96 DECAL SET (225 GRAY XL/XXL) [0G437999] & Below
+827438A01 DECAL SET

809168A96 DECAL SET (250 GRAY) [0G437999] & Below
+809168A01 DECAL SET

809709A97 DECAL SET (225 GRAY LONG)(ALSO ORDER STRIPING DECAL BELOW) [0G438000] & Up

827438A97 DECAL SET (225 GRAY XL/XXL)(ALSO ORDER STRIPING DECAL BELOW) [0G438000] & Up
+827438A01 DECAL SET

809168A97 DECAL SET (250 GRAY)(ALSO ORDER STRIPING DECAL BELOW) [0G438000] & Up
+809168A01 DECAL SET

TRACKER DECALS

809848A96 DECAL SET (TRACKER BY MERCURY)
809854A96 DECAL SET (TRACKER BY MARINER)

OTHER DECALS

850497A97 DECAL SET (225 WHITE)(ALSO ORDER STRIPING DECAL BELOW) [0G438000] & Up
850498A97 DECAL SET (250 WHITE)(ALSO ORDER STRIPING DECAL BELOW) [0G438000] & Up
824911A25 DECAL Striping (ROLL OF 25 FT. - NEED 7.2 FT.) (GRAY AND WHITE) [0G438000] & Up






1998 & Newer MERCRUISER ALPHA TRANSOM W/ENGINE ALPHA - Cat.# 90-80975998

> Mercury Marine [Updated: Oct. 5, 2020] > Sterndrive > Drives > ALPHA ONE (GEN.II)    1998 AND UP > [0L100040 & Up] - Cat.# 90-80975998

DIAGRAM 2496

861063A4 HOUSING ASSEMBLY Driveshaft

DRIVESHAFT HOUSING AND DRIVESHAFT DECALS

DIAGRAM 5067


861431A98 DECAL SET (STANDARD ROTATION)
 861431A99 DECAL SET (STANDARD ROTATION)
861431A04 DECAL SET (STANDARD ROTATION) [0W535000] & Up 1
+ 861431A05 DECAL SET
861446A98 DECAL SET (COUNTER ROTATION)
861446A99 DECAL SET (COUNTER ROTATION)
898111A04 DECAL SET (COUNTER ROTATION) [0W535000] & Up 1
+ 898111A05 DECAL SET



Serial Number: 0L212113 & Up
Model: 6111001LS
Model Version: TRANSOM

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips

    1. Ensure that the surrounding work area and the surface are properly cleaned to avoid contamination.

    90-8M0143239 eng MARCH 2018       © 2018 Mercury Marine      -     Page 1 / 16
