Diagram 432879-05

ENGINE COVER - EVINRUDE

1 0283541 ENGINE COVER ASSY.. 10RC - 10RLC 10EC - 10ELC
1 0283543 ENGINE COVER ASSY.. 10SELC
1 0283906 ENGINE COVER ASSY.. 15RC - 15RLC 15EC - 15ELC
1 0283774 ENGINE COVER ASSY.. TE15RLC
1 0283894 ENGINE COVER ASSY.. TE10RL,TE10EL

0283541, 0283543, 0283906, 0283774, 0283894
0283541 0283543 0283906 0283774 0283894

ENGINE COVER - JOHNSON

1 0432479 ENGINE COVER. TJ10EL
1 0432092 ENGINE COVER ASSY.. 10RC - 10RLC 10EC - 10ELC
1 0432093 ENGINE COVER ASSY.. 10SELC
1 0433537 ENGINE COVER ASSY.. 15RC - 15RLC 15EC - 15ELC
1 0433134 ENGINE COVER ASSY.. TJ15RLC
1 0433473 ENGINE COVER ASSY.. TJ10RL

0432479, 0432092, 0432093, 0433537, 0433134, 0433473
0432479 0432092 0432093 0433537 0433134 0433473

Johnson Decals

4 0331907 APPLIQUE, Front. 10SELC 15RC - 15RLC 10RC - 10RLC - 10EC - 10ELC - 15EC - 15ELC
4 0334864 FRAME, Front. TJ15RLC

8 0332710 PLATE, Applique, front. 10RC - 10RLC 10EC - 10ELC 10SELC
8 0332715 PLATE, Applique, front. 15RC - 15RLC 15EC - 15ELC
8 0335055 PLATE, Frame, Front. TJ15RLC TJ10RL

0433109 DECAL SET. Not Shown 10RC - 10RLC 10EC - 10ELC
0433110 DECAL SET. Not Shown 10SELC
0433111 DECAL SET. Not Shown 15RC - 15RLC 15EC - 15ELC
0433203 DECAL SET.
Use 434737 decal set for 9.9 hp.
Use 434041 decal set for 15 hp.

0433203, 434737,0332710 - 0433109, 0433110 (9.9 -10)
0433203, 434041,0332715, 0335055 - 0433111 (15 hp)

Read more: 1989 1990 Johnson 9.9 hp/15 hp

2000 Evinrude 115
E115FSLSSH FFI, Elec Start, TNT, 20 IN.shaft, wht 2000

ENGINE COVER diagram epc0468

0285386 ENGINE COVER ASSY. - V,Y,Z. 75FPL, 115FPL, 115FL, 90FPL
0285372 ENGINE COVER ASSY. - W,X. 115FSL, FS, FPX, FX

0285386, 0285372
0285386 0285372

EVINRUDE DECALS

13 0214756 *PLATE, Front - W,X. 115FSL, FS, FPX, FX
16 0214755 *DECAL, Wrap - W,X. 115FSL, FS, FPX, FX
15 0213591 *DECAL, Rear - W,X. 115FSL, FS, FPX, FX

0214756, 0214755, 0213591

13 0214747 *PLATE, Front - V,Y,Z. 75FPL, 115FPL, 115FL, 90FPL
16 0214746 *DECAL, Wrap - V,Y,Z. 75FPL, 115FPL, 115FL, 90FPL
15 0214772 *DECAL, Rear - V. 75FPL
15 0213585 *DECAL, Rear - Y. 115FPL, FL
15 0214608 *DECAL, Rear - Z. 90FPL

0214756, 0214746, 0214772 ----75FPL
0214756, 0214746, 0213585 ----115FPL, FL
0214756, 0214746, 0214608 90FPL

PAINT

771227 0771227 PRIMER
771234 0771234 BLACK
771226 0771226 WHITE
771230 0771230 BLUE
772414 0772414 CLEARCOAT

ONE COAT FINISH FOR MIDSECTION AND GEARCASE
BASE COAT PLUS CLEARCOAT FOR UPPER AND LOWER ENGINE COVERS.

Read more: 2000 Evinrude 90/115 HP - 75FPL

Johnson - 2000 115

Engine Cover Diagrama epc0451

1 5001188 ENGINE COVER ASSY. - Z,W,T. 90PL ONLY, 115PL ONLY, 115JPL ONLY (Gray-Red)
1 5001091 ENGINE COVER ASSY. - Y,V. 90SPL, 90PX ONLY, 115SPL, 115PX ONLY
1 5001380 ENGINE COVER ASSY. - X,U. 90VL, 90VX ONLY, 115VL. 115VX ONLY

18 0346706 *DECAL, Sides - Z,W,T. 90PL ONLY, 115PL ONLY, 115JPL ONLY
17 0346690 *DECAL, Rear - Z. 90PL ONLY
19 0346707 *DECAL, Front - Z. 90PL ONLY

19 0346708 *DECAL, Front - W. 115PL ONLY
17 0346961 *DECAL, Rear - W. 115PL ONLY

18 0346476 *DECAL, Sides -Y,X,V,U. 90SPL, 90PX ONLY, 90VL, 90VX ONLY, 115SPL, 115PX ONLY, 115VL. 115VX ONLY
17 0346475 *DECAL, Rear - Y,X. 90SPL, 90PX ONLY, 90VL, 90VX ONLY
19 0346477 *DECAL, Front - Y,X. 90SPL, 90PX ONLY, 90VL, 90VX ONLY

17 0346480 *DECAL, Rear - V,U. 115SPL, 115PX ONLY, 115VL. 115VX ONLY
19 0346481 *DECAL, Front - V,U. 115SPL, 115PX ONLY, 115VL. 115VX ONLY

17 0346696 *DECAL, Rear - T. 115JPL ONLY
19 0346695 *DECAL, Front - T. 115JPL ONLY

20 0346478 *LENS, Port
21 0346479 *LENS, Starboard

Read more: Johnson - 2000 90/115 HP 2-STROKE

ENGINE COVER - JOHNSON DIAGRAM 438703-03A

0438319 MOTOR COVER ASSY. J25RM, J25RML, J25TK, J25TKL
0437365 MOTOR COVER ASSY. BJ25AR, BJ25ARL
0438320 MOTOR COVER ASSY. J25KL, J25QL
0437366 MOTOR COVER ASSY. BJ25K, BJ25KL, BJ25QL
0437360 MOTOR COVER ASSY. BJ35AR, BJ35ARL, HJ35RML
0438322 MOTOR COVER ASSY. J35KL, J35QL
0437363 MOTOR COVER ASSY. BJ35K, BJ35KL, BJ35QL
0438321 MOTOR COVER ASSY. J35RML, J35TKL

ENGINE COVER - EVINRUDE

0284848 MOTOR COVER E25RM, E25RML, E25TK, E25TKL
0284768 MOTOR COVER BE25AR, BE25ARL
0284849 MOTOR COVER E25KL, E25QL
0284769 MOTOR COVER BE25K, BE25KL, BE25QL
0284783 MOTOR COVER BE35AR, HE35RML, BE35ARL
0284767 MOTOR COVER E35KL, E35QL
0284785 MOTOR COVER BE35K, BE35KL, BE35QL
0284764 MOTOR COVER E35RML, E35TKL

0438319, 0437365, 0438320, 0437366, 0437360, 0438322, 0437363, 0438321
0284848, 0284768, 0284849, 0284769, 0284783, 0284767, 0284785, 0284764
0438319 0437365 0438320 0437366 0437360 0438322 0437363 0438321
0284848 0284768 0284849 0284769 0284783 0284767 0284785 0284764

JOHNSON DECALS

5) 0341988 LENS, Jo.,. BJ25AR, BJ25ARL BJ25K, BJ25KL, BJ25QL BJ35AR, BJ35ARL, HJ35RML BJ35K, BJ35KL, BJ35QL

8) 0438444 DECAL SET. J25RM, J25RML, J25TK, J25TKL J25KL, J25QL
8) 0437890 DECAL SET. BJ25AR, BJ25ARL BJ25K, BJ25KL, BJ25QL
8) 0437892 DECAL SET. BJ35AR, BJ35ARL, HJ35RML BJ35K, BJ35KL, BJ35QL (ENDEAVOUR)
8) 0438445 DECAL SET. J35KL, J35QL J35RML, J35TKL

Read more: 1997-1998-1999 JOHNSON 25/35 HP - 2 STROKE 3 CYL
