HIGH PERFORMANCE 450R 4S XL 4 - Cat.# 90-8M0155664

 > Mercury Marine [Updated: Jul. 1, 2020] > Outboard > 4 Stroke > 450 4.6L V8 RACING > [1E083006 & Up] - USA - Cat.# 90-8M0155664



TOP COWL DIAGRAM  68552

8M0159576 TOP COWL ASSEMBLY Black
8M0159577 TOP COWL ASSY COLD FUSION



MERCURY DECALS

68556

Decals Diagram 68556

8M0159581 DECAL SET Top Cowl, 450R
8M0143773 DECAL SET Lower Cowl
8M0151525 DECAL MICON 53 MM, Racing
8M0080153 M-ICON 66 MM Racing
8M0146963 DECAL AMS



Accent Panel Diagram 68558

1 https://garzonstudio.com/store/catalogsearch/result/?q=8M0147691 ACCENT COWL ASSEMBLY Devil Eye Red
1 https://garzonstudio.com/store/catalogsearch/result/?q=8M0147689 ACCENT COWL ASSEMBLY Graphite Grey
1 https://garzonstudio.com/store/catalogsearch/result/?q=8M0148622 ACCENT COWL ASSEMBLY Carbon Fiber
1 NSS NOT SOLD SEPARATE Accent Cowl Assembly Paint Ready

2 8M0159923 DECAL SET Accent Panel, 450R
3 8M0149565 DECAL Mercury, Black Devil Eye Red or Graphite Grey
3 8M0147920 DECAL Mercury, Silver Carbon Fiber
4 8M0080153 DECAL M-ICON 66 MM Racing
5 8M0159582 DECAL REAR 450R
6 8M0149566 DECAL Red, R Graphite Grey or Carbon Fiber option
7 8M0149568 DECAL Black, R Devil Eye Red

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips

    1. Ensure that the surrounding work area and the surface are properly cleaned to avoid contamination.

    90-8M0143239 eng MARCH 2018       © 2018 Mercury Marine      -     Page 1 / 16
