1972 Evinrude 65 hp Triumph – MOTOR COVER ASSY. / DECAL SET

Models: 65272S, 65273S

• 279382 - 0279382 - MOTOR COVER ASSY.

279382, 0279382,

DECAL SET / EMBLEMS (Appliques)

• 11) 0206771 - 0206771 - PLATE, Applique, front
• 12) 0206776 - 0206776 - APPLIQUE, Front
• 14) 0206772 - 0206772 - PLATE, Applique, rear
• 19) 0206777 - 0206777 - APPLIQUE, Rear
• 22) 0206765 - 0206765 - APPLIQUE, Port
• 9)   0206766 - 0206766 - APPLIQUE, Stbd.
• 23) 0206596 - 0206596 - APPLIQUE, "Evinrude"- Order 2

206771, 0206771, 206776, 0206776, 206772, 0206772, 206777, 0206777, 206765, 0206765, 206766, 0206766, 206596, 0206596,

BE200CXECM, BE200TXECM, E200CXECM, E200STLECE, E200TLECM, E200TXECM,

ENGINE COVER -- EVINRUDE -- 200STL, SL, 225STL, SL, GL

• 0285021 - 0285021 - ENGINE COVER ASSY., 200
• 0285022 - 0285022 - ENGINE COVER ASSY., 225STL, SL
• 0285140 - 0285140 - ENGINE COVER ASSY., 225GL

0285021, 0285021, 0285022, 0285022, 0285140, 0285140

DECAL SET

• 19) 0285068 - 0285068 - DECAL SET, 200
• 19) 0285069 - 0285069 - DECAL SET, 225STL, SL
• 19) 0285139 - 0285139 - DECAL SET, 225GL

0285068, 0285068, 0285069, 0285069, 0285139, 0285139

ENGINE COVER-EVINRUDE-200TL,TX,CX,225TX,CX,TZ,CZ,QX,NX,250

• 0284442 - 0284442 - ENGINE COVER ASSY., 200
• 0284443 - 0284443 - ENGINE COVER ASSY., 225
• 0285126 - 0285126 - ENGINE COVER ASSY., 225QX
• 0285128 - 0285128 - ENGINE COVER ASSY., 225NX
• 0285179 - 0285179 - ENGINE COVER ASSY., 250

0284442, 0284442, 0284443, 0284443, 0285126, 0285126, 0285128, 0285128, 0285179, 0285179

DECAL SET

• 19) 0284545 - 0284545 - DECAL SET, 200
• 19) 0284546 - 0284546 - DECAL SET, 225
• 19) 0285130 - 0285130 - DECAL SET, 225QX, NX
• 19) 0285178 - 0285178 - DECAL SET, 250

0284545, 0284545, 0284546, 0284546, 0285130, 0285130, 0285178, 0285178

ENGINE COVER -- EVINRUDE (SE200WTPLG / SE200WTPXG)

• 0285076 - 0285076 - ENGINE COVER ASSY.

0285076, 0285076

DECAL SET

• 15) 0285097 - 0285097 - DECAL SET

0285097, 0285097

ENGINE COVER-JOHNSON-200TL,TX,CX,225TX,CX,TZ,CZ,QX,NX,250

• 0435966 - 0435966 - ENGINE COVER ASSY., 200
• 0435967 - 0435967 - ENGINE COVER ASSY., 225
• 0439625 - 0439625 - ENGINE COVER ASSY., 225QX
• 0439627 - 0439627 - ENGINE COVER ASSY., 225NX
• 0439961 - 0439961 - ENGINE COVER ASSY., 250

0435966, 0435966, 0435967, 0435967, 0439625, 0439625, 0439627, 0439627, 0439961, 0439961

DECAL SET

• 20) 0436348 - 0436348 - DECAL SET, 200
• 20) 0436349 - 0436349 - DECAL SET, 225
• 20) 0439642 - 0439642 - DECAL SET, 225QX, NX
• 20) 0439960 - 0439960 - DECAL SET, 250

0436348, 0436348, 0436349, 0436349, 0439642, 0439642, 0439960, 0439960

ENGINE COVER -- JOHNSON -- 200SL, STL, 225STL, SL, GL

• 0439552 - 0439552 - ENGINE COVER ASSY., 200
• 0439553 - 0439553 - ENGINE COVER ASSY., 225STL, SL
• 0439721 - 0439721 - ENGINE COVER ASSY., 225GL

0439552, 0439552, 0439553, 0439553, 0439721, 0439721

DECAL SET

• 20) 0439557 - 0439557 - DECAL SET, 200
• 20) 0439558 - 0439558 - DECAL SET, 225STL, SL
• 20) 0439641 - 0439641 - DECAL SET, 225GL

0439557, 0439557, 0439558, 0439558, 0439641, 0439641

ENGINE COVER -- JOHNSON (SE200WTPLG / SE200WTPXG)

• 0439345 - 0439345 - ENGINE COVER ASSY.

0439345, 0439345

DECAL SET

• 15) 0439768 - 0439768 - DECAL SET

0439768, 0439768

ACCESSORY TRANSOM PLATE -- OPTIONAL

• 1) 0339015 - 0339015 - TRANSOM PLATE, Johnson - OceanRunner
• 2) 0339026 - 0339026 - TRANSOM PLATE, Evinrude - OceanPro

0339015, 0339015, 0339026, 0339026

Evinrude 0285076, 0284442, 0284443, 0285126, 0285128, 0285179, 0285021, 0285022, 0285140,
Johnson 0439345, 0439552, 0439553, 0439721, 0435966, 0435967, 0439625, 0439627, 0439961,

 MOTOR COVER

• Ref 1 - 0279381 - MOTOR COVER ASSY

• 9 - 0206766 - APPLIQUE, STBD11 - 0206768 - PLATE, APPLIQUE FRONT
• 12 - 0206597 - APPLIQUE, FRONT
• 14 - 0206769 - PLATE, APPLIQUE REAR
• 19 - 0206599 - APPLIQUE, COVER REAR
• 22 - 0206596 - APPLIQUE, EVINRUDE
• 23 - 0206765 - APPLIQUE, PORT

•  0279483 - DECAL SET
•  0279484 - DECAL SET

MODELS: 50202C, 50203C, 50272C, 50273CA,
50202C 50203C 50272C 50273CA

1966 EVINRUDE MOTOR COVER GROUP – 9-1/2 HP  (Models 9622A, 9623A)

• 1) 278692 - MOTOR COVER ASSEMBLY

• 1) 205590 - APPLIQUE, Front - 9.5 hp
• 1) 205318 - EMBLEM, Rear - E LOGO
• 1) 205589 - APPLIQUE, Rear
• 1) 278731 - DECAL SET

LOWER UNIT GROUP

• 1) 203260 - PLATE, throttle control - Sticker

205590, 205590, 205318, 205318, 205589, 205589, 278731, 278731, 2023260, 2023260

MOTOR COVER GROUP – 9-1/2 HP 1966 (Models 9622A, 9623A)

• 1) 278692 - MOTOR COVER ASSEMBLY
• 2) 205213 - SOUND BLANKET, Top
• 3) 204476 - FASTENER, Applique - 5
• 4) 205590 - APPLIQUE, Front
• 5) 554355 - RIVET, Hook to cover - 4
• 6) 205233 - HOOK, Front
• 7) 278755 - TILT HANDLE & SCREW ASSY.
• 8) 312299 - SCREW, Tilt handle -2
• 9) 306407 - WASHER, Tilt handle - 2
• 10) 205214 - SOUND BLANKET, Side
• 11) 205318 - EMBLEM, Rear
• 12) 205210 - SEAL, Motor cover
• 13) 205589 - APPLIQUE, Rear
• 14) 205702 - HOOK, Rear upper
• 15) 310598 - NUT, Switch retaining
• 16) 379638 - SHORTING SWITCH ASSY.
• 17) 310680 - TERMINAL, Leads - 2
• 18) 310572 - HOUSING, Connector - 2
• 19) 278608 - PANEL ASSY., Port
• 20) 310801 - FASTENER, Panel - 4
• 21) 278788 - KNOB & ROD, Choke
• 22) 205231 - KNOB, Slow speed adjust
• 23) 278734 - PANEL ASSY., Starboard
• 24) 310801 - FASTENER, Panel - 4
• 25) 312382 - RETAINING RING - 2
• 26) 312482 - SPRING, Choke knob
• *) 278731 - DECAL SET
• *)205667 - OWNER'S MANUAL
• *) 379893 - ACCESSORY, Remote control adapter kit
• *) 203260 - PLATE, Throttle control (Sticker)

*Not shown.

INDENTED PART NAMES INDICATE THAT THESE PARTS ARE INCLUDED IN PRECEDING ASSEMBLY ORDER ALL PARTS FROM YOUR LOCAL AUTHORIZED DEALER
