Evinrude/Johnson EVINRUDE 1972 9.50 HP
Models: 9222M 9223M

MOTOR COVER

1) 0279395 MOTOR COVER ASSEMBLY
4) 0206569 APPLIQUE, Front
19) 0315792 CONTROL PANEL

0279476 DECAL SET

Evinrude/Johnson EVINRUDE 2007 90 E90DSLSUA

ENGINE COVER

0285671 ENGINE COVER Assy - BLUE | Includes all decals except 'HP' This part replaces 0285650 ENGINE COVER Assy - BLUE
0285672 ENGINE COVER Assy - WHITE| Includes all decals except 'HP' This part replaces 0285651 ENGINE COVER Assy - WHITE

0285671, 0285650, 0285672, 0285651,
0285671 0285650 0285672 0285651

EVINRUDE DECALS WHITE MODELS

1) 0215545 EVINRUDE | Included with 'ENGINE COVER Assy'
1) 0215665 EVINRUDE - Front | Included with 'ENGINE COVER Assy'
2) 0352506 *BRP LOGO | Included with 'ENGINE COVER Assy'
3) 0215547 EVINRUDE E-TEC - Port | Included with 'ENGINE COVER Assy'
4) 0215546 EVINRUDE E-TEC - Starboard | Included with 'ENGINE COVER Assy'
5) 0215559 STRIPE, - Port | Included with 'ENGINE COVER Assy'
6) 0215560 STRIPE - Starboard | Included with 'ENGINE COVER Assy'
7) 0215544 90 HP Rear
8) 0215663 90 HP Front
9) 0351222 SALTWATER EDITION - Port
10) 0351237 SALTWATER EDITION - Starboard

0215545, 0215665, 0215547, 0215546, 0351222, 0351237, 0215559, 0215560, 0215544, 0215663, 0352506,
0215545 0215665 0215547 0215546 0351222 0351237 0215559 0215560 0215544 0215663 0352506

11) 0216969 EU, RCD II Compliant – Lower This part replaces 0215558.
12) 0334435 **DECAL  Owner Attn.

0215774 3 Star

PROFILE DRAWING

JOHNSON 1996 130 J130TXADA

1996 ENGINE COVER - JOHNSON Diagram

0437620 ENGINE COVER ASSY. Standard Styling (Smoke)
0437005 ENGINE COVER ASSY. Ocean Runner Styling (White)
0437632 ENGINE COVER ASSY. ( ocean Runner Styling ( White) 130CX
0284799 ENGINE COVER ASSY. EVINRUDE

0437620, 0437005, 0437632, 0284799

Johnson decals

21) 0437887 DECAL SET Standard Styling (Smoke)
17) 0341339 LENS, 130, Front & rear
18) 0340590 APPLIQUE, Logo, port & stbd.
19) 0340591 APPLIQUE, Johnson, port & stbd.

21) 0437170 DECAL SET Ocean Runner Styling (White)

Evinrude/Johnson EVINRUDE 1987 40 HP E40TLCUD

ENGINE COVER - EVINRUDE Diagram

1) 0283034 ENGINE COVER ASSY., 50 Ev.
1) 0283033 ENGINE COVER ASSY., 50 Ev.
1) 0283032 ENGINE COVER ASSY., 40 Ev.
1) 0283031 ENGINE COVER ASSY., 40 Ev.
1) 0283232 ENGINE COVER ASSY., Evinrude 35 models

0283034, 0283033, 0283032, 0283031, 0283232
0283034 0283033 0283032 0283031 0283232

Evinrude Decals

11) 0210459 PLATE, Applique, front 50 model
14) 0210629 PLATE, Applique, rear 50 model

0210459, 0210629, 028333,
0210459 0210629 028333

11) 0210497 PLATE, Applique, front 40 model
14) 0210625 PLATE, Applique, rear 40 model

0210497, 0210625, 028333,
0210497 0210625 028333

11) 0210887 PLATE, Applique, front 35 model
14) 0210891 PLATE, Applique, rear 35 model

0210887, 0210891, 028333,
0210887 0210891 028333,

26) 0283338 DECAL SET
