1991 Evinrude 115 hp - E115TLEIE (88/90/100/115, TE 115/TE90, 90/115 Jet)

1991 Evinrude 115 hp - E115TLEIE

88/90/100/115, TE 115/TE90, 90/115 Jet

Diagram 434248-04

http://epc.brp.com/cgi-bin/ImgServ.exe/convert?ilFN=E:\\EmpartWeb\\data\\41\\434248\04.tif&ilSC=55&ilIV=0&ilBR=0&ilIF=P&ilRE=8


ENGINE COVER - EVINRUDE

1 0283708 ENGINE COVER ASSY., 88 models
1 0283619 ENGINE COVER ASSY., 90 models
1 0282305 ENGINE COVER ASSY., 90 Jet, (65)
1 0284062 ENGINE COVER ASSY. TE90 Models Only
1 0283685 ENGINE COVER ASSY., 100 models
1 0283945 ENGINE COVER ASSY., 115 models
1 0282299 ENGINE COVER ASSY., 115 Jet, (80)
1 0284063 ENGINE COVER ASSY.. TE 115 Models Only

0283708, 0283619, 0282305, 0284062, 0283685, 0283945, 0282299, 0284063
0283708 0283619 0282305 0284062 0283685 0283945 0282299 0284063

ENGINE COVER - JOHNSON
0433887, 0434558, 0433890, 0433889, 0434574, 0434559, 0433892, 0433891, 0434573, 0433888
0433887 0434558 0433890 0433889 0434574 0434559 0433892 0433891 0434573 0433888



EVINRUDE DECALS

27 0283782 DECAL SET, 88 models
27 0283783 DECAL SET, 90/115 models
27 0284273 DECAL SET, 90/115. TE 115 Models Only TE90 Models Only
27 0284274 DECAL SET, 90/115 Jet
27 0283784 DECAL SET, 100

PLATES AND APPLIQUES MADE AS DECALS

21 0211371 PLATE, Front & rear, 88 models (2 decals)
21 0211241 PLATE, Front, 90/115 models, except Jet
21 0211703 PLATE, Front, 90/115 Jet
21 0211580 PLATE, Front. TE90 Models Only
21 0211581 PLATE, Front. TE 115 Models Only


24 0210311 APPLIQUE, V-4 100
25 0210305 APPLIQUE, Ev., 100

2001 Evinrude 70 hp - E70PL4SIA 4-Stroke

2001 Evinrude - EN 70 hp
E70PL4SIA 4-Stroke, Elec. Start, TNT, Blue, 20 IN.



5032518 ENGINE COVER Assy

1 5032518 ENGINE COVER Assy



EVINRUDE DECALS

4 5032522 DECAL, Front
5 5032523 DECAL, Rear
6 5032524 DECAL, Cover, Stbd
7 5032526 DECAL, Cover, Port

13 5032527 LABEL, Fuel limitation


PAINT

  • 771227 0771227 Primer. (PPG Code - DP40401. One Coat Finish For Midsection And Gearcase)
  • 771234 0771234 Black - 1. (PPG Code - 9696. One Coat Finish For Midsection And Gearcase)
  • 771230 0771230 Blue. (PPG Code - 18319. One Coat Finish For Midsection And Gearcase)
    (PPG Code - 18320. Base Coat Plus Clearcoat For Upper And Lower Engine Covers)
  • 772414 0772414 Clearcoat

1989 Johnson 110 HP - TJ110TLCEM

ENGINE COVER - JOHNSON

Diagram 432895-05

ENGINE COVER - JOHNSON


1
0398809 ENGINE COVER ASSY., 88
0433123 ENGINE COVER ASSY., 90. TJ90 Models Only
0432573 ENGINE COVER ASSY., 90. Metallic Gray
0432464 ENGINE COVER ASSY., 90. White
0433124 ENGINE COVER ASSY., 110. TJ110 Models Only
0432574 ENGINE COVER ASSY., 110. Metallic Gray
0432463 ENGINE COVER ASSY., 110. White
0433023 ENGINE COVER ASSY., 100STL

0398809, 0433123, 0432573, 0432464, 0433124, 0432574, 0432463, 0433023
0398809 0433123 0432573 0432464 0433124 0432574 0432463 0433023

EVINRUDE ENGINE COVER ENGINE COVER ASSY:
0283708 (88 models)
0283619 (90 models)
0283766 (TE90 Models Only)
0283685 (100STL)
0283620 (110 models)
0283767 (TE110 Models Only)

0283708, 0283619, 0283766, 0283685, 0283620, 0283767
0283708 0283619 0283766 0283685 0283620 0283767



Johnson Outboard Decals


25 0433146 DECAL SET, 88 models
25 0433147 DECAL SET, 90 models
25 0433148 DECAL SET, 110 models
25 0433207 DECAL SET, 90, 110.
     Use 0434045 on phase III styling on Johnson 90 hp Tracker models.
     Use 0434046 on 1989 Johnson 110 hp tracker models with phase 1 styling.
25 0433149 DECAL SET, 100STL models


18 0334224 APPLIQUE, Rear, 88 models
18 0334565 PLATE, Rear, 90 models
18 0334564 PLATE, Rear, 110 models


21 0334563 PLATE, Applique front, 88/90/110
21 0335059 PLATE, Applique, front. TJ90 Models Only
21 0335068 PLATE, Applique, front. TJ110 Models Only
21 0334224 PLATE, Applique, front & rear, 88

Exhaust Housing Stripe

36 0210769 DECAL, Exh. hsg., Ev., 88 models
36 0211388 DECAL, Exh. hsg., Ev., 90/110
36 0332731 DECAL, Exh. hsg., Jo., 90/110

1989 Johnson 110 HP models:
J110MLCEM 1989
J110TLAEM 1989
J110TLCEM 1989
J110TXCEM 1989
TJ110TLCEM 1989
TJ110TXCEM 1989

This Johnson 0433148 DECAL SET, 110 models fits the following models and components:
88 HP: VJ88MSLCER, J88MSLCER
90 HP: J90TLAEM, J90TLCEM, TJ90TLCEM 1989
100 hp: J100STLCEM
110 hp: J110MLCEM, J110TLAEM, J110TLCEM, J110TXCEM, TJ110TLCEM, TJ110TXCEM



2009-2013 Evinrude 150/175 200 - (60° V6, 2.6 L)/135 E-TEC H.0.

 ENGINE COVER Diagram EPC4161

-) 0285704 ENGINE COVER Assy, Blue - Std.
-) 0285706 ENGINE COVER Ay, Blue - 150 H.O.
-) 0285705 ENGINE COVER Assy, White - Std.
-) 0285707 ENGINE COVER Assy, White - 150 H.O.
-) 0285733 ENGINE COVER Assy, Smoke - 150 H.O.
1) 0351799 *CAP, Blue
1) 0351800 *CAP, White



0285704, 0285706, 0285705, 0285707, 0285733, 0351799, 0351800,
0285704 0285706 0285705 0285707 0285733 0351799 0351800



Diagram EPC4345 - 200 - (60° V6, 2.6 L) | E200DCXISF | DECALS

EVINRUDE E-TEC Decals

1) 0215667 EVINRUDE - Front.
1) 0215545 EVINRUDE - Rear.

2) 0215747 150 - Front & Rear (2 decals)
4) 0215750 175 - Front & Rear (2 decals)
5) 0215752 200 - Front & Rear (2 decals)


11) 0215733 EVINRUDE E-TEC - Port.
12) 0215734 EVINRUDE E-TEC - Stbd.
15) 0215886 STRIPE - Port.
16) 0215887 STRIPE - Stbd.

EVINRUDE E-TEC H.O. WAVE decals

3) 0215821 150 H.O. - Front & Rear (2 decals)
11) 0215858 EVINRUDE E-TEC, Port - H.O.
12) 0215859 EVINRUDE E-TEC, Stbd - H.O.
13) 0215860 H.O. WAVE, Port.
14) 0215861 H.O. WAVE, Stbd.

Other Evinrude E-TEC Decals

6) 0352505 BRP Logo - Front & Rear. (2 decals)
7) 0215558 EU 2006 - Lower
8) 0215875 "100th ANNIVERSARY" - 5 in.
9) 0215873 "100th ANNIVERSARY" - 6 in.
10) 0215896 SALTWATER EDITION - Stbd bracket
17) 0334435 DECAL, Owner Attention
18) 0215774 DECAL, Calif - 3 Star

This Evinrude H.O. WAVE fits the following models:

150HP
2009 E150DCXSEA,E150DPXSEA,E150DSLSEA,E150HSLSEC
2010 E150DCXISF, E150DCXISM, E150DPXISF, E150DPXISM, E150DSLISF, E150DSLISM, E150HSLISF, E150HSLISR
2011 E150DCXIIB, E150DPXIIB, E150DSLIIB, E150HSLIIA
2012 DE150CXINS, DE150PXINS
2012 E150DCXINE, E150DPXINE, E150DSLINE, E150HSLINM
AA MODELS DE150CXAAA, DE150CXAAB, DE150CXAAC, DE150PXAAA, DE150PXAAB, DE150PXAAC
AA MODELS E150DCXAAA, E150DCXAAB, E150DCXAAC, E150DPXAAA, E150DPXAAB, E150DPXAAC, E150DSLAAA, E150DSLAAB, E150HSLAAA, E150HSLAAB

175HP
2009 E175DCXSEA, E175DPXSEA, E175DSLSEA
2010 E175DCXISF, E175DCXISM, E175DPXISF, E175DPXISM, E175DSLISF, E175DSLISM
2011 E175DCXIIB, E175DPXIIB, E175DSLIIB
2012 E175DCXINE, E175DPXINE, E175DSLINE
AA MODELS E175DCXAAA, E175DCXAAB, E175DCXAAC, E175DPXAAA, E175DPXAAB, E175DPXAAC, E175DSLAAA, E175DSLAAB

200 - (60° V6, 2.6 L)
2009 E200DCXSEM, E200DPXSEM, E200DSLSEM
2010 E200DCXISB, E200DCXISF, E200DPXISB, E200DPXISF, E200DSLISB, E200DSLISF
2011 E200DCXIIE, E200DHXIIB, E200DPXIIE
2012 DE200CXINS, DE200PXINS 2012 Decals - White
2012 E200DCXIND, E200DPXIND, E200DSLIND
AA MODELS DE200CXAAA, DE200CXAAB, DE200CXAAC, DE200PXAAA, DE200PXAAB, DE200PXAAC
AA MODELS E200DCXAAA, E200DCXAAB, E200DCXAAC, E200DPXAAA, E200DPXAAB, E200DPXAAC, E200DSLAAA, E200DSLAAB

135HP
AA MODELS E135DHXAAC, E135HCXAAC, E135HSLAAB
BLUE ENGINES
2009 E150DBXSEA,E150DHLSEA,E150DPLSEA
2010 E150DBXISF, E150DBXISM, E150DHLISF, E150DHLISM, E150DPLISF, E150DPLISM
2011 E150DBXIIB, E150DHLIIB,E150DPLIIB
2012 E150DBXINE,E150DHLINE,E150DPLINE
2013 E150DBXAAA,E150DBXAAC,E150DBXAAB,E150DHLAAA,E150DHLAAB,E150DPLAAA,E150DPLAAB

175HP
2009 E175DPLSEA,E175DPLSEA
2010 E175DPLISF, E175DPLISF, E175DPLISM
2011 E175DPLIIB
2012 E175DPLINE
2013 E175DPLAAA, E175DPLAAB


200HP (60° V6 2.6L)
2009 E200DPLSEM
2010 E200DPLISB, E200DPLISF
2011 E200DPLIIE
2012 E200DPLIND
2013 E200DPLAAA, E200DPLAAB AA Model


135HP
2013 E135DHLAAB

More Articles …

  1. EVINRUDE 2005 40/50/60 hp E-TEC - Bombardier
  2. 1989 Johnson GT 300 V8 - J300PLCEM
  3. 1968 Johnson - 6 hp CD-25
  4. EVINRUDE 2006-2007 40/50/60/ hp E-TEC - BRP

Subcategories

  • Mercury-Mariner-Tracker-Force Outboard Decals

    DECAL DRY APPLICATION

    IMPORTANT: This document guides our dealers, boatbuilders, and company service personnel in the proper installation or service of our products. If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician. Improper installation or servicing of the Mercury product could result in damage to the product or personal injury to those installing or operating the product.
    NOTE:After completing installation, place these instructions with the product for the owner's future use.
    IMPORTANT: This decal set must be applied dry. Do not use a soap and water mixture to apply this decal set.

    Tools, Materials, and Surface Requirements

    Tools and Materials

    • Decal application squeegee (3M® Applicator PA 1 Gold - recommended)
    • Air release tool (3M Air Release Tool 391x) or a straight pin - used to remove trapped air bubbles
    • Clean microfiber towel (Meguiar’s® Supreme Shine Microfiber Towel - recommended)
    • Spray bottles and labels for each cleaning solution
    • Cleaning solution:
      a. Liquid dishwashing soap
      b. Isopropyl alcohol
      IMPORTANT: Identify each spray bottle of cleaning solution with a label.

    Surface Requirements

    Special attention is required when applying decals to certain surfaces, including primed, painted, and certain plastics. All
    painted surfaces must be cured per the manufacturer's requirements. When applying decals to plastic surfaces, allow proper
    time for out gassing.

    Surface Preparation

    Application Temperature

    Apply the decal when the surface and ambient air temperature is between 16-373 °C (61-99 °F).
    NOTE: Applying the decal near the minimum temperature specification, the adhesive bond will develop more slowly than temperature in the mid to upper specification range.

    Step One General Cleaning

    IMPORTANT: Do not shortcut the cleaning process. All of the surfaces are considered contaminated prior to a thorough
    surface cleaning preparation.

    1. Mix a solution of 29.5 cc (1 fl oz) liquid dishwashing detergent with 3.7 Liter (4 US qt) of warm water.
    2. Rinse cowl with clean water.
    3. Dry the cowl with a clean Meguiar‘s Supreme Shine Microfiber Towel.
    4. Avoid detergents or preparations that contain waxes, oils, or lotions.

    Step Two Solvent Cleaning

    1. Mix a solution of isoprooyl alcohol and water to a 1:1 ratio. Store in a spray bottle and identify the solution with a label.
    2. Saturate a clean paper towel with the isopropyl alcohol and water solution.
    3. Wipe the cowl with the saturated towel followed immediately with a lint-free towel before the solution evaporates.
    NOTE: Isopropyl a/coho/ evaporates quickly. You must Wipe the surface immediately after applying the solution.
    4. When the paper towel becomes contaminated with dirt, discard it and use a clean paper towel saturated with the
    isopropyl alcohol and water solution.
    5. Ensure the surface has no contamination and is completely dry.
    6. Start to apply the decals immediately after solvent cleaning.

    Decal Application

    Application Tips
