1981 Johnson - 4.50/7.50

J5RCIC 1981

MOTOR COVER DIAGRAM 392300-04

0390625, 0281511, 0281687, 0281525, 0391530
0390625 0281511 0281687 0281525 0391530

JOHNSON DECALS

MOTOR COVER-4.5 JOHNSON MODELS
0391530 MOTOR COVER ASSY., Johnson. MODELS WITH AUXILIARY FUEL TANK

0391315 DECAL SET, Johnson. MODELS WITH INTEGRAL FUEL TANK
0391531 DECAL SET, Johnson. MODELS WITH AUXILIARY FUEL TANK

MOTOR COVER,7.5 JOHNSON MODELS
0390625 MOTOR COVER ASSY., Johnson

0391316 DECAL SET, Johnson

EVINRUDE DECALS

MOTOR COVER-4.5 EVINRUDE MODELS

0281511 MOTOR COVER ASSY., Evinrude. MODELS WITH INTEGRAL FUEL TANK
0281687 MOTOR COVER ASSY., Evinrude. MODELS WITH AUXILIARY FUEL TANK

0281528 DECAL SET, Evinrude. MODELS WITH INTEGRAL FUEL TANK
0281689 DECAL SET, Evinrude. MODELS WITH AUXILIARY FUEL TANK

MOTOR COVER,7.5 EVINRUDE MODELS
0281525 MOTOR COVER ASSY., Evinrude

0281651 DECAL SET, Evinrude

1995 Evinrude 18 JET E25JREOS 2 CYL IN-LINE

Diagram 437817-03A
1 0284809 ENGINE COVER ASSY.

EVINRUDE JET DECALS

6 0212810 PLATE, Frame, front
13 0212811 PLATE, Frame, rear
16 0212497 LENS, Ev., port & stbd. Order 2
20 0284824 DECAL SET

1 0284713 ENGINE COVER ASSY.. 20E - 20EL
1 0284714 ENGINE COVER ASSY.. 25E - 25EL - 25ER - 25ERL
1 0284133 ENGINE COVER ASSY.. 25SE - 25SEL
1 0284396 ENGINE COVER ASSY.. 20SE - 20SEL
1 0284715 ENGINE COVER ASSY.. 30E - 30EL

0284713, 0284714, 0284133, 0284396, 0284715, 0284809
0284713 0284714 0284133 0284396 0284715 0284809

EVINRUDE DECALS

18 0284329 DECAL SET. 20SE - 20SEL
6 0212709 PLATE, Frame, front, 20. 20E - 20EL
15 0212710 PLATE, Frame, rear, 20. 20E - 20EL

18 0284331 DECAL SET. 25SE - 25SEL
6 0211504 PLATE, Frame, front, 20. 20SE - 20SEL
15 0211453 PLATE, Frame, rear, 25. 25SE - 25SEL 20SE - 20SEL

18 0284824 DECAL SET. 20E - 20EL 25E - 25EL - 25ER - 25ERL 30E - 30EL
6 212711 PLATE, Frame, front, 25. 25E - 25EL - 25ER - 25ERL
15 0212712 PLATE, Frame, rear, 25. 25E - 25EL - 25ER - 25ERL
6 0211452 PLATE, Frame, front, 25. 25SE - 25SEL
11 0210990 APPLIQUE, EV - XP. 25SE - 25SEL
6 0212713 PLATE, Frame, front, 30. 30E - 30EL
15 0212714 PLATE, Frame, rear, 30. 30E - 30EL

16 0212497 LENS, Ev., port & stbd.. 20E - 20EL 25E - 25EL - 25ER - 25ERL 30E - 30EL

2002 - 2006 Johnson 150 hp decal set Graphite models

HP150HP J150GLSDE 2006 Decals Graphite Models

EPC3089

1 5005011 ENGINE COVER Assy - WHITE.
1 5005028 ENGINE COVER Assy - GRAPHITE.

JOHNSON DECALS GRAPHITE MODELS DIAGRAM EPC3651a

1 0352504 DECAL, BRP Logo.
2 0350241 DECAL, "JOHNSON", Port/Stbd.
3 0350233 DECAL, Stripe - Stbd. (SMOKE - Engine Cover.)
4 0350235 DECAL, Stripe - Port. (SMOKE - Engine Cover.)
5 0350239 150 HP, Front/Rear
6 0350236 DECAL, "JOHNSON", Front/Rear.

Read more: 2002 - 2006 Johnson 150/175 hp decal set Graphite models

E15HTSXABF

ENGINE COVER Diagram EPC4357

1 0285825 ENGINE COVER, Blue. 15 H.O. Models
1 0285826 ENGINE COVER, White. 15 H.O. Models
1 0285846 ENGINE COVER, Graphite. 15 H.O. Models
1 0285823 ENGINE COVER, Blue. 25 & 30 HP Models
1 0285824 ENGINE COVER, White. 25 & 30 HP Models
1 0285856 ENGINE COVER, Graphite. 25 & 30 HP Models

0285825, 0285826, 0285846, 0285823, 0285824, 0285856
0285825 0285826 0285846 0285823 0285824 0285856
0285825,0285826,0285846,0285823,0285824,0285856,

DECALS diagram EPC4641

EVINRUDE DECALS

1 0216385 EVINRUDE E-TEC - Port & Starboard - Blue. All Models 2 Decals

4 0216462 DECAL, Stripe HO - Port - Blue. 15 HP Models
5 0216463 DECAL, Stripe HO - Starboard - Blue. 15 HP Models
6 0216464 "EVINRUDE 15 HO" HP - Blue (front)
9 0216480 "15 HO" HP - Blue (rear)

0216385, 0216462, 0216463, 0216464, 0216480

2 0216451 DECAL, Stripe, Port - Blue. 25-30 HP Models
3 0216452 DECAL, Stripe, Starboard - Blue. 25-30 HP Models
7 0216453 "EVINRUDE 25" HP - Blue (front)
10 0216481 "25" HP - Blue (rear)

0216385, 0216451, 0216452, 0216453, 216481

8 0216454 "EVINRUDE 30" HP - Blue (front)
11 0216482 "30" HP - Blue (rear)

0216385, 0216451, 0216452, 0216454, 0216482

1 0216398 EVINRUDE E-TEC - Port & Starboard - White. All Models 2 Decals

4 0216467 DECAL, Stripe HO - Port - White. 15 HP Models
5 0216468 DECAL, Stripe HO - Starboard - White. 15 HP Models
6 0216469 "EVINRUDE 15 HO" HP - White (front)
9 0216477 "15 HO" HP - White (rear)

0216398, 0216467, 0216468, 0216469, 0216477

2 0216456 DECAL, Stripe, Port - White. 25-30 HP Models
3 0216457 DECAL, Stripe, Starboard - White. 25-30 HP Models
7 0216458 "EVINRUDE 25" HP - White (front)
10 0216478 "25" HP - White (rear)

0216398, 0216456, 0216457, 0216458, 0216478

8 0216459 "EVINRUDE 30" HP - White (front)
11 0216479 "30" HP - White (rear)

0216398, 0216456, 0216457, 0216459, 0216479

1 0216551 EVINRUDE E-TEC - Port & Starboard - Graphite. 15 HP Models 2 Decals
4 0216549 DECAL, Stripe HO - Port - Graphite. 15 HP Models
5 0216550 DECAL, Stripe HO - Starboard - Graphite. 15 HP Models
6 0216547 "EVINRUDE 15 HO" HP - Graphite (front)
9 0216548 "15 HO" HP - Graphite (rear)

0216551, 0216549, 0216550, 0216547, 0216548

1 0216702 EVINRUDE E-TEC - Port & Starboard - Graphite. 25-30 HP Models 2 Decals
2 0216652 DECAL, Stripe, Port - Graphite. 25-30 HP Models
3 0216653 DECAL, Stripe, Starboard - Graphite. 25-30 HP Models
7 0216658 "25" HP - Graphite (front)
10 0216659 "25" HP - Graphite (rear)

0216702, 0216652, 0216653, 0216658, 0216659

8 0216660 "30" HP - Graphite (front)
11 0216661 "30" HP - Graphite (rear)

0216702, 0216652, 0216653, 0216660, 0216661

12 0352506 BRP LOGO.
13 0355633 DECAL, Owner Attention
14 0215558 EVINRUDE "EU" 2006
15 0215774 DECAL, Calif - 3 Star. See Administrative Bulletin 2004-02(A) for order requirements
16 0215896 "APPROVED FOR SALTWATER"
17 0353772 DECAL, RPM. DTE, DTL, DR Models only
18 0353417 DECAL, Gear shift. DTE, DTL, DR Models only
19 0354413 DECAL, Tilt release. DTE, DTL, DR Models only
20 0355634 DECAL, Emergency stop clip - Blue. DTE, DTL, DR Models only
20 0355621 DECAL, Emergency stop clip - White. DTE, DTL, DR Models only
21 0355620 DECAL, Start in Gear Warning. DTE, DTL, DR Models only

Read more: 2014 2015 Evinrude 15 hp - AB Models
